1402-27
[return to Table of Contents]
SWING DOOR HARDWARE
HINGE PINS & WASHERS
CONTAINERS: DOMCON, ISO & REEFER
TRAILERS: DRY & REEFER VAN

HINGE PINS
WITH STOPPER EDGE O.D. 1/2"
Ø12.7 MM
A

MODEL A SUB FOR MATERIAL FINISH WEIGHT
3.66"
1402-1651 93 MM CHPN-001-1 CARBON STEEL SELF-COLOR 0.2 LBS
0.09 Kg
4.13"
1402-2270 105 MM CHPN-003-1 STAINLESS STEEL SELF-COLOR 0.25 LBS
0.11 Kg

O.D. 0.48"
HINGE PINS Ø12.2 MM
WITHOUT EDGE A
1402
MODEL A SUB FOR MATERIAL FINISH WEIGHT
1402-6227 3-11/16" BCSP-24001/94 STAINLESS STEEL SELF-COLOR 0.2 LBS
0.09 Kg
94 MM
4-1/32"
1402-6872 102 MM SAEJIN PH30001/3 STAINLESS STEEL SELF-COLOR 0.21 LBS
0.09 Kg
4-1/2"
1402-6216 114 MM CHPN-001-4 STAINLESS STEEL SELF-COLOR 0.23 LBS
0.1 Kg
5" 0.26 LBS
1402-6871 127 MM JINDO R26223-1270 STAINLESS STEEL SELF-COLOR 0.12 Kg
5-7/8"
1402-8988 149 MM CIMC GA04-A06-U0 STAINLESS STEEL SELF-COLOR 0.29 LBS
0.13 Kg
HINGE PINS O.D. 1/2"
FOR REEFER CONTAINERS Ø12.7 MM
A
B
MODEL A B SUB FOR MATERIAL FINISH WEIGHT
4.84" 5.12" 0.3 LBS
1402-8655 MAERSK STAINLESS STEEL SELF-COLOR
123 MM 130 MM 0.13 Kg
5.39"
5.12"
1402-6256 130 MM 137 MM MAERSK 7810961 STAINLESS STEEL SELF-COLOR 0.31 LBS
0.14 Kg
7810800
5.24" 5.67" 0.32 LBS
1402-6258 MAERSK 7810801 STAINLESS STEEL SELF-COLOR
133 MM 144 MM 0.15 Kg
6.1" 6.38" 0.36 LBS
1402-7558 155 MM 162 MM MAERSK STAINLESS STEEL SELF-COLOR 0.16 Kg
HINGE WASHER
I.D. 9/16" O.D. 7/8" 1/16" / 1.43 MM
Ø13 MM Ø22.2 MM
MODEL SUB FOR FITS MATERIAL FINISH WEIGHT
CSX, JINDO, 0.01 LBS
1402-4674-SS JINDO R26452-1601 STAINLESS STEEL SELF-COLOR
PACER 48', 53' 0.005 Kg
SAE 1/2" FLAT WASHER I.D. 17/32"
Ø13.5 MM
7/64"
MODEL MATERIAL FINISH WEIGHT O.D. 1-1/16" 2.7 MM
1402-4535 CARBON STEEL ZINC-PLATED 0.02 LBS Ø27 MM
0.01 Kg
