1402-10
[return to Table of Contents]
SWING DOOR HARDWARE
HINGES
REEFER CONTAINERS

MODEL 1402-8106 MODEL 1402-8107
CIMC style, bolt-on, CIMC style, bolt-on,
works w/ 1/2" pin, works w/ 1/2" pin,
includes brass bushing includes brass bushing
I.D. 1-9/16" 2-3/8" I.D. 13/32"
I.D. 13/32" Ø40 MM 60 MM Ø10.5 MM
Ø10.5 MM x 6 HOLES x 6 HOLES

3-15/16" 2-7/8" 3-15/16" 2-7/8"
100 MM 73 MM 100 MM 73 MM

1-9/16" 1-9/16"
5-3/16" 40 MM 5-3/16" 40 MM
132 MM 132 MM
I.D. 1/2" 9-11/16" / 246 MM
9-11/16" / 246 MM 1402
I.D. 1/2" Ø13 MM 1/8"
Ø13 MM 3 MM
1-3/8"
1-3/8" 35 MM 5/16"
35 MM 5/16" 8 MM
8 MM 13/16"
13/16" 3/8" 20 MM I.D. 2-7/16"
3/8" 20 MM 4-1/2" 9 MM 4-1/2" Ø62 MM
9 MM 115 MM 115 MM 9-1/8"
9-1/8" / 232 MM 232 MM
SUB FOR: CIMC DA18-A207-S0 FITS: CIMC 40' REEFER
SUB FOR: CIMC DA18-A206-S0 FITS: CIMC 40' REEFER WORKS WITH: DOOR BUMPER 1402-7260
MATERIAL: STEEL FINISH: HOT-DIP GALVANIZED MATERIAL: STEEL FINISH: HOT-DIP GALVANIZED
WEIGHT: 3.82 LBS / 1.73 Kg WEIGHT: 3.56 LBS / 1.61 Kg

MODEL 1402-8748 MODEL 1402-8749
SPECIAL ORDER ONLY SPECIAL ORDER ONLY
Maersk MCI Denmark style, Maersk MCI Denmark style,
bolt-on, works w/ 1/2" pin, bolt-on, works w/ 1/2" pin,
includes brass bushing includes brass bushing
I.D. 13/32"
I.D. 13/32" Ø10.5 MM
Ø10.5 MM x 4 HOLES x 5 HOLES

4" 2-3/4"
101 MM 69.6 MM 4" 2-3/4"
101 MM 1-3/8" 69.6 MM
35 MM
3-1/16" 5-1/2"
78.1 MM 140 MM
4-3/4" 3-1/16" 5-1/2"
9-13/16" / 249.9 MM 120 MM 78.1 MM 140 MM
I.D. 1/2" 9-13/16" / 249.9 MM
Ø13 MM I.D. 1/2"
Ø13 MM
1-1/2"
38 MM 5/16" 1-1/2"
8 MM 38 MM 5/16"
2-9/16" / 65 MM 8 MM
2-9/16" / 65 MM
9-1/4" / 235.6 MM
9-1/4" / 235.6 MM
FITS: MAERSK MCI DENMARK 40' REEFER FITS: MAERSK MCI DENMARK 40' REEFER
MATERIAL: STEEL FINISH: HOT-DIP GALVANIZED MATERIAL: STEEL FINISH: HOT-DIP GALVANIZED
WEIGHT: 4.2 LBS / 1.91 Kg WEIGHT: 4.65 LBS / 2.11 Kg

904-696-0010
E-mail: sales@buffersusa.com
1402-10 11/15/21
