1402-06
[return to Table of Contents]
SWING DOOR HARDWARE
HINGES
REEFER CONTAINERS

MODEL 1402-6362 MODEL 1402-6363
Maersk style, bolt-on, Maersk/Carlisle style,
works w/ 1/2" pin, bolt-on, works w/ 1/2" pin,
includes brass bushing includes brass bushing

I.D. 3/8"
1" / 25 MM I.D. 3/8" Ø10 MM x 6 HOLES
Ø10 MM x 6 HOLES
I.D. 5/32"
I.D. 5/32" Ø4 MM
Ø4 MM 4" 2-3/4"
2-13/16" 2-3/4" 101 MM 69.6 MM
71 MM 69.6 MM
2"
2" 4-5/8"
4-5/8" 50.8 MM 50.8 MM
1" / 25 MM 118 MM 118 MM
9-13/16" / 249.9 MM 1402
4" 9-13/16" / 249.9 MM
101 MM
I.D. 1/2" I.D. 1/2"
Ø13.2 MM
1-7/16" Ø13.2 MM 1-7/16"
37 MM 5/16" 37 MM 5/16"
8 MM 8 MM
1-1/8" 13/16"
5/16" 28 MM 3-5/8" 5/16" 21 MM 3-5/8"
8 MM 92 MM 9-1/4" 8 MM 92 MM
235.6 MM 9-1/4" / 235.6 MM
SUB FOR: MAERSK 7811408, SAEJIN 90408 SUB FOR: MAERSK 7811411, SAEJIN 90411, PH12004
FITS: MAERSK (Type C) MCIQ 40' REEFER FITS: MAERSK (Type A) MCIQ 40' REEFER, CARLISLE
MATERIAL: STEEL FINISH: HOT-DIP GALVANIZED MATERIAL: STEEL FINISH: HOT-DIP GALVANIZED
WEIGHT: 4.1 LBS / 1.86 Kg WEIGHT: 4.07 LBS / 1.85 Kg

MODEL 1402-6364 MODEL 1402-7028
Maersk style, bolt-on, Singamas style, bolt-on,
works w/ 1/2" pin, works w/ 1/2" pin,
includes brass bushing includes brass bushing
I.D. 3/8" I.D. 3/8"
Ø10 MM x 6 HOLES Ø10 MM x 6 HOLES
I.D. 5/32"
Ø4 MM
4" I.D. 5/16" 2-3/4"
101 MM Ø7.6 MM 69.6 MM 5" 3-15/16"
127 MM 100 MM
2"
4-5/8" 50.8 MM
118 MM 1-15/16"
4-1/8" 50 MM
9-13/16" / 249.9 MM 105 MM
I.D. 1/2" 9-7/16" / 239 MM
1-7/16" Ø13.2 MM
37 MM 5/16" I.D. 1/2"
8 MM 1-3/8" Ø13 MM
13/16" 35 MM 5/16"
5/16" 21 MM 3-5/8" 8 MM
8 MM 92 MM 13/16"
5/16" 21.3 MM 3-9/16"
9-1/4" / 235.6 MM 8 MM 90 MM 8-7/8"
225 MM
SUB FOR: MAERSK 7811412
FITS: MAERSK (Type B) MCIQ 40' REEFER FITS: SINGAMAS 40' REEFER
MATERIAL: STEEL FINISH: HOT-DIP GALVANIZED MATERIAL: FAB. STEEL FINISH: HOT-DIP GALVANIZED
WEIGHT: 4.1 LBS / 1.86 Kg WEIGHT: 4.81 LBS / 2.18 Kg

904-696-0010
E-mail: sales@buffersusa.com
1402-6 11/15/21
