Page 132 - Buffers USA 2024 Container Hardware Catalog FlipBook

1401-09
[return to Table of Contents]
SWING DOOR LOCKING SYSTEMS
BLOXWICH-STYLE COMPONENTS
TOP CAMS
DOMCON, ISO & REEFER CONTAINERS

2" 1-3/8" MODEL 1401-6969-TL/TR
51 MM 35 MM
TOP CAMS
for Narrow Header
3-3/8"
86 MM 2"
51 MM
4-1/2"
1-5/16" 115 MM
32.6 MM
2-1/2"
63.5 MM
Model 1401-6969-TL
shown dimensioned. MODEL
Model 1401-6969-TR O.D. 1" 1401-6969-TL MODEL
Top Left
is a mirror image. Ø26 MM 1401-6969-TR
Top Right
1401 SUB FOR: BLOXWICH 10085 (TL) & 10084 (TR), SAEJIN 87004/6L, H-01/3L (TL) & 87003/6R, H-02/3R (TR)
FITS: 48' & 53' CONTAINERS WORKS WITH: BUFFERS 1401-2189-L/R, 1401-2190-L/R, 1401-6965-TL/TR KEEPERS
MATERIAL: FORGED STEEL FINISH: HOT-DIP GALVANIZED (HDG) WEIGHT: 1.04 LBS / 0.47 Kg

904-696-0010
E-mail: sales@buffersusa.com
1401-11 7/24/24
