Page 131 - Buffers USA 2024 Container Hardware Catalog FlipBook

1401-08
[return to Table of Contents]
SWING DOOR LOCKING SYSTEMS
BLOXWICH-STYLE COMPONENTS
TOP & BOTTOM CAMS
DOMCON, ISO & REEFER CONTAINERS

MODEL 1401-1992-L/R
3-15/16" O.D. 1" BOTTOM CAMS
99.3 MM Ø26 MM w/ Security Hole
2-1/2"
1-1/2" 63.5 MM
39 MM 5"
126.8 MM
I.D. 5/8"
Ø15.5 MM 2-1/2"
63.2 MM
Model 1401-1992-R
shown dimensioned.
MODEL MODEL
Model 1401-1992-L 1401-1992-L 1401-1992-R
is a mirror image. Bottom Left Bottom Right
SUB FOR: BLOXWICH 13506/D-L, 13506/D-R, CIMC D23-01C, SAEJIN 87024-L & 87022-R 1401
WORKS WITH: 1401-1993-L/-R KEEPERS MATERIAL: FORGED STEEL
FINISH: HOT-DIP GALVANIZED WEIGHT: 1.55 LBS / 0.7 Kg

2" 1" MODEL 1401-2194-L/R
45.5 MM 25.4 MM TOP & BOTTOM CAMS

1-1/2"
38 MM
3" 5"
76 MM 126.8 MM
Model 1401-2194-L O.D. 1" 2-3/16"
shown dimensioned. Ø26 MM 56 MM
Model 1401-2194-R MODEL MODEL
is a mirror image. 1401-2194-L 1401-2194-R
Top Right or Bottom Left Top Left or Bottom Right
SUB FOR: BLOXWICH 10081 (L) & 10080 (R), CIMC D23-01A (L) & D23-01B (R), SAEJIN 87004 (L) & 87003 (R)
WORKS WITH: 1401-2189-L/R & 1401-2190-L/R KEEPERS MATERIAL: CAST STEEL
FINISH: HOT-DIP GALVANIZED WEIGHT: 1.3 LBS / 0.59 Kg

1-7/8" 1-3/16" MODEL 1401-6968-L/R
47 MM 30 MM TOP & BOTTOM CAMS
w/ Kick-out Ridge
3-1/8"
79 MM 2-1/2"
63.4 MM
5"
127 MM
1-1/2"
Model 1401-6968-L 38 MM 2-1/2"
shown dimensioned. 63.4 MM
Model 1401-6968-R
is a mirror image. O.D. 1"
Ø25 MM
MODEL MODEL
SUB FOR: BLOXWICH 10083 (L) & 10082 (R), SAEJIN 87004/2L (L) & 87003/2R (R) 1401-6968-L 1401-6968-R
WORKS WITH: 1401-2189-L/R & 1401-2190-L/R KEEPERS MATERIAL: FORGED STEEL Top Right or Top Left or
FINISH: HOT-DIP GALVANIZED (Slung) WEIGHT: 1.45 LBS / 0.66 Kg Bottom Left Bottom Right

904-696-0010
E-mail: sales@buffersusa.com
1401-10 10/17/23
