ALUMINUM FLAT BARS

REEFER CONTAINERS | REEFER VAN TRAILERS

A NOTE: SOME SIZES ARE SPECIAL ORDER
B
MODEL A B LENGTH WEIGHT
1313-2296 1/8" / 3.2 MM 2" / 50.8 MM 12' / 3,658 MM 3.5 LBS / 1.6 Kg
1313-2297 1/8" / 3.2 MM 2" / 50.8 MM 20' / 6,096 MM 5.8 LBS / 2.6 Kg
1313-2298 1/8" / 3.2 MM 3" / 76.2 MM 12' / 3,658 MM 5.3 LBS / 2.4 Kg
1313-2299 1/8" / 3.2 MM 3" / 76.2 MM 20' / 6,096 MM 8.8 LBS / 4 Kg
1313-2300 1/8" / 3.2 MM 4" / 101.6 MM 12' / 3,658 MM 7.1 LBS / 3.2 Kg
1313-2301 1/8" / 3.2 MM 4" / 101.6 MM 20' / 6,096 MM 11.8 LBS / 5.3 Kg
1313-6810 3/16" / 4.76 MM 1" / 25.4 MM 12' / 3,658 MM 2.6 LBS / 1.2 Kg
1313-6810-16 3/16" / 4.76 MM 1" / 25.4 MM 16' / 4,877 MM 4 LBS / 1.8 Kg
1313-6811 3/16" / 4.76 MM 1" / 25.4 MM 20' / 6,096 MM 4.4 LBS / 2 Kg
1313-6812 3/16" / 4.76 MM 2" / 50.8 MM 12' / 3,658 MM 5.3 LBS / 2.4 Kg 1313
1313-6812-16 3/16" / 4.76 MM 2" / 50.8 MM 16' / 4,877 MM 7.1 LBS / 3.2 Kg
1313-6813 3/16" / 4.76 MM 2" / 50.8 MM 20' / 6,096 MM 8.8 LBS / 4 Kg
1313-6814 3/16" / 4.76 MM 3" / 76.2 MM 12' / 3,658 MM 8 LBS / 3.6 Kg
1313-6815 3/16" / 4.76 MM 3" / 76.2 MM 20' / 6,096 MM 13.2 LBS / 6 Kg
1313-6816 3/16" / 4.76 MM 4" / 101.6 MM 12' / 3,658 MM 10.6 LBS / 4.8 Kg
1313-6817 3/16" / 4.76 MM 4" / 101.6 MM 20' / 6,096 MM 17.6 LBS / 8 Kg
1313-6818 3/16" / 4.76 MM 5" / 127 MM 12' / 3,658 MM 13.2 LBS / 6 Kg
1313-6819 3/16" / 4.76 MM 5" / 127 MM 20' / 6,096 MM 22 LBS / 10 Kg
1313-2400 1/4" / 6.35 MM 1" / 25.4 MM 12' / 3,658 MM 3.5 LBS / 1.6 Kg
1313-2401 1/4" / 6.35 MM 1" / 25.4 MM 20' / 6,096 MM 5.8 LBS / 2.6 Kg
1313-2402 1/4" / 6.35 MM 2" / 50.8 MM 12' / 3,658 MM 7.1 LBS / 3.2 Kg
1313-2403 1/4" / 6.35 MM 2" / 50.8 MM 20' / 6,096 MM 11.8 LBS / 5.4 Kg
1313-2404 1/4" / 6.35 MM 3" / 76.2 MM 12' / 3,658 MM 10.6 LBS / 4.8 Kg
1313-2405 1/4" / 6.35 MM 3" / 76.2 MM 20' / 6,096 MM 17.6 LBS / 8 Kg
1313-2406 1/4" / 6.35 MM 4" / 101.6 MM 12' / 3,658 MM 14 LBS / 6.4 Kg
1313-2407 1/4" / 6.35 MM 4" / 101.6 MM 20' / 6,096 MM 23.4 LBS / 10.6 Kg
1313-2408 1/4" / 6.35 MM 5" / 127 MM 12' / 3,658 MM 17.5 LBS / 7.9 Kg
1313-2409 1/4" / 6.35 MM 5" / 127 MM 20' / 6,096 MM 29.2 LBS / 13.2 Kg
1313-2410 1/4" / 6.4 MM 6" / 152.4 MM 12' / 3,658 MM 21.1 LBS / 9.6 Kg
1313-2411 1/4" / 6.4 MM 6" / 152.4 MM 20' / 6,096 MM 35.2 LBS / 16 Kg
1313-2412 5/16" / 7.94 MM 2" / 50.8 MM 12' / 3,658 MM 8.8 LBS / 4 Kg
1313-2413 5/16" / 7.94 MM 2" / 50.8 MM 20' / 6,096 MM 14.6 LBS / 6.6 Kg
1313-2414 5/16" / 7.94 MM 3" / 76.2 MM 12' / 3,658 MM 13.2 LBS / 6 Kg
1313-2415 5/16" / 7.94 MM 3" / 76.2 MM 20' / 6,096 MM 22 LBS / 10 Kg
1313-2416 5/16" / 7.94 MM 3 1/4" / 82.55 MM 12' / 3,658 MM 14.3 LBS / 6.5 Kg
1313-2417 5/16" / 7.94 MM 3 1/4" / 82.55 MM 20' / 6,096 MM 23.8 LBS / 10.8 Kg
1313-2418 5/16" / 7.94 MM 3 3/4" / 95.25 MM 12' / 3,658 MM 16.4 LBS / 7.5 Kg
1313-2419 5/16" / 7.94 MM 3 3/4" / 95.25 MM 20' / 6,096 MM 27.4 LBS / 12.4 Kg
1313-2420 5/16" / 7.94 MM 4" / 101.6 MM 12' / 3,658 MM 17.5 LBS / 7.9 Kg
1313-2421 5/16" / 7.94 MM 5" / 127 MM 12' / 3,658 MM 22 LBS / 10 Kg
1313-6284 3/8" / 9.5 MM 1" / 25.4 MM 12' / 3,658 MM 5.3 LBS / 2.4 Kg
1313-6285 3/8" / 9.5 MM 1" / 25.4 MM 20' / 6,096 MM 8.8 LBS / 4 Kg
1313-6286 3/8" / 9.5 MM 2" / 50.8 MM 12' / 3,658 MM 10.6 LBS / 4.8 Kg
1313-6287 3/8" / 9.5 MM 2" / 50.8 MM 20' / 6,096 MM 17.6 LBS / 8 Kg
1313-6288 3/8" / 9.5 MM 2 1/2" / 63.5 MM 12' / 3,658 MM 13.2 LBS / 6 Kg
1313-6289 3/8" / 9.5 MM 2 1/2" / 63.5 MM 20' / 6,096 MM 22 LBS / 10 Kg
1313-6290 3/8" / 9.5 MM 3" / 76.2 MM 12' / 3,658 MM 15.8 LBS / 7.2 Kg
1313-6685 3/8" / 9.5 MM 3" / 76.2 MM 20' / 6,096 MM 26.4 LBS / 12 Kg
1313-6686 3/8" / 9.5 MM 4" / 101.6 MM 12' / 3,658 MM 21.45 LBS / 9.73 Kg
1313-6687 3/8" / 9.5 MM 4" / 101.6 MM 20' / 6,096 MM 35.2 LBS / 16 Kg
1313-6688 3/8" / 9.5 MM 5" / 127 MM 12' /3,658 MM 26.3 LBS / 11.9 Kg
1313-6689 3/8" / 9.5 MM 5" / 127 MM 20' / 6,096 MM 43.8 LBS / 19.9 Kg
1313-6690 1/2" / 12.7 MM 1" / 25.4 MM 12' / 3,658 MM 7.1 LBS / 3.2 Kg
1313-6691 1/2" / 12.7 MM 1" / 25.4 MM 20' / 6,096 MM 11.8 LBS / 5.4 Kg
1313-6692 1/2" / 12.7 MM 2" / 50.8 MM 12' / 3,658 MM 14 LBS / 6.4 Kg
1313-6693 1/2" / 12.7 MM 2" / 50.8 MM 20' / 6,096 MM 23.4 LBS / 10.6 Kg
1313-6694 1/2" / 12.7 MM 3" / 76.2 MM 12' / 3,658 MM 21.1 LBS / 9.6 Kg
1313-6695 1/2" / 12.7 MM 3" / 76.2 MM 20' / 6,096 MM 35.2 LBS / 16 Kg
1313-6696 1/2" / 12.7 MM 4" / 101.6 MM 12' / 3,658 MM 28.3 LBS / 12.8 Kg
1313-6697 1/2" / 12.7 MM 4" / 101.6 MM 20' / 6,096 MM 46.8 LBS / 21.2 Kg
1313-6698 1/2" / 12.7 MM 5" / 127 MM 12' / 3,658 MM 35.2 LBS / 16 Kg
