1101-31
[return to Table of Contents]
TWISTLOCKS – CHASSIS TYPE
w/ LIGHT HOLES
CHASSIS

7" MODEL 1101-3707-L
178 MM
3-1/2" 3-1/2" MODEL 1101-3707-R
89 MM 89 MM J.B. Hunt style w/ Low-profile Head

3-3/4"
95 MM
7-1/4"
184 MM
1101
3-1/2"
89 MM
45º

1-1/8"
28.5 MM
1-5/16" MODEL 1101-3707-L MODEL 1101-3707-R
33.5 MM ffor Rear Roadside for Rear Curbside
4" (& Front Curbside if 20') (& Front Roadside if 20')
102 MM 2 Light Holes 1 Light Hole

I.D. 2-5/16"
Ø59 MM SUB FOR:
5-11/16" 6-5/16"
145 MM 160 MM SCHULZ F33NS-45-LP-XX-JBH
FINISH: WELDABLE PRIMER
WEIGHT: 28 LBS / 12.7 Kg

MODEL 1101-3707-L is shown dimensioned.
MODEL 1101-3707-R is the mirror opposite (w/ only one light hole). • Cast steel Housing & forged steel Pin
• Meets AAR specifications for Rail use
EXPLODED VIEW • Easy-to-operate Gravity Latch
• Angled corner for Side & Rear Light visibility
1105-7470
PIN
1110-4549
DETENT BALL
(2 pcs.) MODEL 1110-8400
LIGHT HOLE PLUG
Weld-on
1110-4550
DETENT SPRING
I.D. 3/4"
Ø19 MM
1110-4503 1109-3707-1L O.D. 2-5/8" 3/8"
HOUSING
9 MM
Ø66 MM
GREASE FITTING for 1101-3707-L
(2 pcs.) Twistlock CONVERTS Ø2-5/16" LIGHT HOLE TO Ø3/4"
1109-3707-1R MATERIAL: CAST STEEL FINISH: WELDABLE PRIMER
HOUSING WEIGHT: 0.3 LBS / 0.136 Kg
for 1101-3707-R
Twistlock
I.D. 3/16" MODEL 1110-8674
Ø4.8 MM
1110-3706-19L x 3 HOLES LIGHT HOLE PLUG
1110-4773-G5 LATCH SPRING Bolt-on
HEX BOLT for 1101-3707-L
Twistlock
1108-1345 1110-4542 1110-3706-19R I.D. 3/4"
LATCH HEX NUT LATCH SPRING Ø19 MM
for 1101-3707-R O.D. 3-1/8" 1/8"
1110-4511 Twistlock Ø79.4 MM 3.5 MM
HEX NUT
1110-4529-G8 CONVERTS Ø2-5/16" LIGHT HOLE TO Ø3/4"
HEX BOLT
1107-1344 MATERIAL: STEEL FINISH: WELDABLE PRIMER
HANDLE WEIGHT: 0.28 LBS / 0.127 Kg
904-696-0010
E-mail: sales@buffersusa.com
1101-31 9/13/22
