1101-33
[return to Table of Contents]
TWISTLOCKS – EURO TYPE
RETRACTABLE SCREWDOWN, SWAP BODY
CHASSIS

7-1/16" MODEL 1101-1320
180 MM
3-9/16" 3-9/16"
90 MM 90 MM

2-15/16"
75 MM
5-7/8"
150 MM
2-15/16"
75 MM 1101

1-3/16"
30 MM
1-1/4"
32 MM 7/16"
11 MM

6-5/16" 4-7/16"
160.5 MM 112 MM

9-7/16" O.D. 5/8"
240.5 MM Ø16 MM
RETRACTED
5-1/2"
139.7 MM

FINISH: WELDABLE PRIMER
EXPLODED VIEW
WEIGHT: 23.4 LBS / 10.61 Kg
1110-4502
DETENT SPRING
(2 pcs.)
1105-1320-2 • Special design that engages and retracts
PIN 1110-4501 w/ Container still loaded on Chassis
DETENT BALL
1110-4587 (4 pcs.) • For use on ISO Standard Chassis Trailers
SPLIT ROLL PIN or Swap-Body Chassis
• Exceeds ADR 6.8.1.2 strength requirements
• Load criteria based on 18,000 Kg total mass,
as specified by ADR 6.8.2.1.2
1110-4588
1109-1320-3 GREASE FITTING
SHEAR BLOCK (2 pcs.)
1110-1319-5 1105-1320-INNER CONTAINS:
SUPPORT PLATE
1105-1320-2 PIN (209 MM LONG UNDER HEAD)
1110-4501 DETENT BALL (4 pcs.)
1110-4502 DETENT SPRING (2 pcs.)
1109-1319-1 1109-1320-3 SHEAR BLOCK
HOUSING 1110-4588 GREASE FITTING (2 pcs.)
1110-1319-5 SUPPORT PLATE
1110-4587 SPLIT ROLL PIN
1109-1129-14 HAND NUT
1109-1129-14 1107-1320-4 HANDLE
PIN NUT
1110-4586-G8.8 1110-4585-G8.8 HEX BOLT
LOCK NUT 1110-4585-G8.8 1110-4586-G8.8 HEX NUT
HEX BOLT
1107-1320-4 ALSO AVAILABLE: 1105-1320-INNER-MOD
HANDLE w/ LONGER PIN (222 MM) UNDER HEAD.

904-696-0010
E-mail: sales@buffersusa.com
1101-33 9/20/22
