TWISTLOCKS – EURO TYPE
NON-RETRACTABLE SCREWDOWN
CHASSIS

6-5/16" MODEL 1101-3240-NRS
160 MM
Blair style
3-1/8" 3-1/8"
80 MM 80 MM
2-15/16"
75 MM
5-5/16"
135 MM
2-3/8"
1101 60 MM

1-1/16"
26 MM
1-3/8"
35 MM 1/2"
12 MM

4"
4-7/8" 4-5/16" O.D. 1/2" 100 MM
124 MM 109.8 MM Ø12 MM

5-5/8" 6-3/4"
142 MM 171.5 MM

NOTE: Handle welded by installer.
EXPLODED VIEW

SUB FOR: BLAIR 149
FINISH: WELDABLE PRIMER
1105-2029 WEIGHT: 18.1 LBS / 8.21 Kg
PIN

• Non-handed design; locks to either left or right
• Euro-dimensioned Top & Back Plates
1110-4562
DETENT • Grease Fitting
BALL
• Cast Steel Housing & Forged Steel Pin
1110-4577
DETENT • Screwdown Nut for tighter securing
SPRING
1109-3240-1
HOUSING
1110-4616
SET SCREW
1110-4503 1110-2009
GREASE FITTING PIN NUT

1107-1542-A
HANDLE

904-696-0010
