1101-27
[return to Table of Contents]
TWISTLOCKS – CHASSIS TYPE
NON-RETRACTABLE w/ LIGHT HOLES
HEAVY DUTY for SHALLOW CORNER CASTINGS
CHASSIS

7" MODEL 1101-3407-L
178 MM
3-1/2" 3-1/2" MODEL 1101-3407-R
89 MM 89 MM

3-3/4"
95 MM
7-1/4"
184 MM
1101
3-1/2"
89 MM
45º
3/4" / 19 MM MODEL 1101-3407-L MODEL 1101-3407-R
for Rear Roadside for Rear Curbside
4-3/16" (& Front Curbside if 20') (& Front Roadside if 20')
1-1/4" 107 MM 2 Light Holes 1 Light Hole
32 MM
FINISH: WELDABLE PRIMER
I.D. 2-5/16" WEIGHT: 26.8 LBS / 12.2 Kg
Ø59 MM 5-9/16"
141.5 MM
• Heavy-duty cast steel Housing & forged steel Pin
• Meets AAR specifications for Rail use
11/16" / 17 MM 6-1/4" • Easy-to-operate Gravity Latch
158 MM
MODEL 1101-3407-L is shown dimensioned. • Unused Light Holes can be blanked off with
MODEL 1101-3407-R is the mirror opposite (w/ only one light hole). 1110-1209 Rubber Hole Plug
• Ledges extended to protect Lights
EXPLODED VIEW • Fits most shallow Corner Castings

1110-4501 • Angled corner for Side & Rear Light visibility
DETENT BALL
(2 pcs.)
1110-4502 MODEL 1110-8400
DETENT
SPRING 1105-3406-2-MOD LIGHT HOLE PLUG
PIN Weld-on
1109-3207-1-L I.D. 3/4"
HOUSING Ø19 MM
for 1101-3407-L O.D. 2-5/8" 3/8"
1110-4503 Twistlock Ø66 MM 9 MM
GREASE
FITTING 1109-3207-1-R CONVERTS Ø2-5/16" LIGHT HOLE TO Ø3/4"
HOUSING MATERIAL: CAST STEEL FINISH: WELDABLE PRIMER
1110-3706-19L for 1101-3407-R
LATCH SPRING Twistlock WEIGHT: 0.3 LBS / 0.136 Kg
for 1101-3407-R
Twistlock
I.D. 3/16" MODEL 1110-8674
1110-3706-19R Ø4.8 MM
LATCH SPRING x 3 HOLES LIGHT HOLE PLUG
for 1101-3407-L Bolt-on
Twistlock
1110-4542
HEX NUT I.D. 3/4"
1110-4556-G5 Ø19 MM
HEX BOLT 1110-4769-G8 O.D. 3-1/8" 1/8"
3.5 MM
HEX BOLT Ø79.4 MM
1108-1207-18
LATCH CONVERTS Ø2-5/16" LIGHT HOLE TO Ø3/4"
1110-4511 1107-3206-4 MATERIAL: STEEL FINISH: WELDABLE PRIMER
HEX NUT HANDLE WEIGHT: 0.28 LBS / 0.127 Kg

904-696-0010
E-mail: sales@buffersusa.com
1101-27 9/13/22
