Page 88 - Buffers USA 2024 Chassis Hardware Catalog FlipBook

1101-30
[return to Table of Contents]
TWISTLOCKS – CHASSIS TYPE
w/ LIGHT HOLES
CHASSIS

7" MODEL 1101-3706-L
178 MM
MODEL 1101-3706-R
3-1/2" 3-1/2"
89 MM 89 MM J.B. Hunt style w/ Low-profile Head

3-3/4"
95 MM ABS LIGHT
HOLE
7-1/4"
184 MM
1101
3-1/2"
89 MM

1-1/8"
28.5 MM MODEL 1101-3706-L MODEL 1101-3706-R
1-5/16" for Rear Roadside for Rear Curbside
33.5 MM (& Front Curbside if 20') (& Front Roadside if 20')
4" 3 Light Holes 2 Light Holes
102 MM

SUB FOR: SCHULZ F33NS-LP-JBH-XX-2
I.D. 2-5/16"
Ø59 MM 5-11/16" FINISH: WELDABLE PRIMER
145 MM WEIGHT: 28 LBS / 12.7 Kg

• Heavy-duty cast steel Housing & forged steel Pin
6-5/16" • Meets AAR specifications for Rail use
MODEL 1101-3706-L is shown dimensioned. 160 MM
MODEL 1101-3706-R is the mirror opposite (w/ only two light holes). • Easy-to-operate Gravity Latch
• Unused Light Holes can be blanked off with
1110-1209 Rubber Hole Plug
EXPLODED VIEW
• Ledges extended to protect Lights
1105-7470
PIN
1110-4549
DETENT BALL MODEL 1110-8400
(2 pcs.)
LIGHT HOLE PLUG
Weld-on
1110-4550 1109-3706-1-L
DETENT SPRING HOUSING
I.D. 3/4"
for 1101-3706-L Ø19 MM
Twistlock O.D. 2-5/8" 3/8"
1110-4503 1109-3706-1-R Ø66 MM 9 MM
GREASE FITTING HOUSING
(2 pcs.) for 1101-3706-R CONVERTS Ø2-5/16" LIGHT HOLE TO Ø3/4"
Twistlock MATERIAL: CAST STEEL FINISH: WELDABLE PRIMER
WEIGHT: 0.3 LBS / 0.136 Kg
I.D. 3/16" MODEL 1110-8674
Ø4.8 MM
1110-3706-19L x 3 HOLES LIGHT HOLE PLUG
LATCH SPRING Bolt-on
1110-4773-G5 for 1101-3706-L
Twistlock
HEX BOLT
1110-3706-19R
1108-1345 1110-4542 LATCH SPRING I.D. 3/4"
LATCH HEX NUT for 1101-3706-R Ø19 MM
Twistlock O.D. 3-1/8" 1/8"
3.5 MM
Ø79.4 MM
1110-4511
HEX NUT CONVERTS Ø2-5/16" LIGHT HOLE TO Ø3/4"
1107-1344 1110-4529-G8 MATERIAL: STEEL FINISH: WELDABLE PRIMER
HANDLE HEX BOLT WEIGHT: 0.28 LBS / 0.127 Kg

904-696-0010
E-mail: sales@buffersusa.com
1101-30 9/19/22
