1105-60
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-8629

1-1/4"
31.8 MM 1/16"
1.6 MM
O.D. 2"
Ø50.8 MM
3-3/4"
5-1/16" 95.3 MM
128.6 MM
I.D. 5/8" 6-1/16" 2"
Ø16 MM 154 MM 50.8 MM
1105

O.D. 1-1/2"
Ø38.1 MM
MATERIAL: FORGED STEEL FINISH: RED PRIMER
WEIGHT: 4.5 LBS / 2.04 Kg

2" MODEL 1105-8640
50.8 MM UNDRILLED, High Cone,
9" x 1-3/4"

3-7/8"
98.4 MM
9" 2-1/4"
228.5 MM
57.2 MM

O.D. 1-3/4" SUB FOR: PENZ 15-14-C MATERIAL: FORGED STEEL
Ø44.5 MM
FINISH: PRIMER WEIGHT: 8.2 LBS / 3.72 Kg

MODEL 1105-8779
1-1/16" Low Profile for Penz 90-41
27.5 MM series Drop-In Twistlocks

4-1/8"
I.D. 7/16" 104 MM
Ø11 MM 2-9/16"
9/16" I.D. 7/16" 65.5 MM 4-1/8"
15 MM 5-1/8" Ø10.5 MM 104 MM 2-3/8"
130 MM 59.5 MM
I.D. 9/16"
Ø15 MM

O.D. 1-1/2"
Ø38 MM SUB FOR: PENZ 15-156F FITS: PENZ 90-41-XXF & 90-41/ST-XXF TWISTLOCKS
WORKS WITH: BUFFERS 1107-1400-L/-R (for 90-41), 1107-1647-L/-R (for 90-41/ST) HANDLES
MATERIAL: FORGED STEEL FINISH: RED PRIMER WEIGHT: 4.47 LBS / 2.03 Kg
