1106-05
[return to Table of Contents]
PINLOCK PINS

CHASSIS

PIN MODEL 1106-1417-2
HANDLE MODEL 1107-1417-4
HANDLE

THESE PARTS ARE SOLD SEPARATELY.
4-3/4" THE PIN & HANDLE MUST BE WELDED
TOGETHER AFTER INSTALLATION.
PIN

1106
O.D.
Ø1-1/2"
O.D.
Ø5/8"
LH CONFIGURATION RH CONFIGURATION
(Roadside) (Curbside)
3-1/4"
5-1/2"
6-15/16"

SUB 1106-1417-2 PIN FOR: PENZ 30-28 & 30-28/CR SUB 1107-1417-4 HANDLE FOR: PENZ 20-111
1106-1417-2 PIN FITS: BUFFERS 1103-1417-L/R, 1103-1517-L/R, PENZ 90-20-XX, 90-20/CR-XX PINLOCKS
1107-1417-4 HANDLE FITS: BUFFERS 1103-1417-L/R, 1103-1617-L/R, PENZ 90-19/H-XX PINLOCKS
MATERIAL: FAB. STEEL FINISH: PRIMER
1106-1417-2 PIN WEIGHT: 2.4 LBS / 1.09 Kg 1107-1417-4 HANDLE WEIGHT: 0.6 LBS / 0.27 Kg

MODEL 1106-1469
Supplied w/ Handle welded on

O.D.
Ø1-1/2"
1"
I.D. Ø13/32" I.D. Ø13/32"
COMPARE AGAINST PIN
1-1/2"
& HANDLE # 1106-1358
6-13/16" 5-7/16"
7-7/8"

SUB FOR: PENZ 20-84HDC
FITS: BUFFERS 1103-1624-L/R, PENZ 90-14HDC-XX & SCHULZ FB88HL-XX PINLOCKS
MATERIAL: FAB. STEEL FINISH: PRIMER WEIGHT: 4.55 LBS / 2.06 Kg

904-696-0010

E-mail: sales@buffersusa.com
1106-5 10/16/23
