1105-57
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-7340-L
MODEL 1105-7340-R

2"
50.8 MM 1105-7340-L 1105-7340-R
3-7/8"
98.4 MM
O.D. 2-3/16" 45º
Ø55 MM 3-3/8"
1/2"
2-1/4"
12.7 MM 85.7 MM 57 MM
1105
4-3/8"
O.D. 1-1/2" 111.1 MM
Ø38.1 MM SUB FOR: PENZ 15-125-XX MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 4.63 LBS / 2.1 Kg

MODEL 1105-7341
1-1/4"
31.8 MM 1/16"
1.6 MM 1-5/16"
33.3 MM
O.D. 2"
Ø50.8 MM
3-3/4"
I.D. 7/16" 95.3 MM
7-9/16" Ø11.1 MM
192.1 MM 6-13/16" 2"
173 MM
6-13/16" 50.8 MM
I.D. 5/16" 173 MM I.D. 5/8"
Ø7.9 MM Ø16.7 MM

O.D. 1-1/2"
Ø38.1 MM SUB FOR: PENZ 15-159F MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 4.9 LBS / 2.22 Kg

MODEL 1105-7353

1-1/4"
31.8 MM 1/16"
1.6 MM 1-1/16"
27 MM
O.D. 2"
Ø50.8 MM 3-3/4"
I.D. 3/8" 95.3 MM
4-9/16" 5-3/16" Ø9.5 MM
115.9 MM 2"
131.8 MM
50.8 MM
I.D. 9/16"
Ø14.3 MM
O.D. 1-1/2"
Ø38.1 MM
SUB FOR: PENZ 15-118 MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 3.8 LBS / 1.72 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-57 10/19/23
