TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-7470
1-1/8"
28.5 MM 1/16" for Buffers 3606-LP, 3706, 3707 series
1.5 MM & Schulz F33NS-LP series Twistlocks
O.D. 1-7/8"
Ø48 MM
3-11/16"
I.D. 7/16" 1-7/8" 7" 94 MM
Ø12 MM 48 MM 7-9/16" 177 MM
192 MM
2"
O.D. 1-1/2" I.D. 1/2" 50 MM
Ø38 MM Ø13 MM
1105
FITS: BUFFERS 1101-3606-LP-L/R, 1101-3706-L/R, 1101-3707-L/R,
SCHULZ F33NS-LP-XX & F33NS-45-LP-XX TWISTLOCKS
WORKS WITH: 1107-1344 HANDLE & 1108-1345 LATCH
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 5.2 LBS / 2.36 Kg

MODEL 1105-7657

1-3/16"
30 MM

3-11/16"
I.D. 1/4"
Ø6.4 MM 94 MM
5-1/2" 5-1/2"
2-1/16" 139.7 MM 6-1/4" 139.7 MM 2-1/4"
52.4 MM 158.8 MM 56 MM
I.D. 5/8" I.D. 1/4"
Ø16 MM Ø6.4 MM
O.D. 1-1/2"
Ø38 MM
MATERIAL: FORGED STEEL FINISH: PRIMER
WEIGHT: 4.37 LBS / 1.98 Kg

SPECIAL ORDER ONLY MODEL 1105-8459-2
Low Profile for CIMC Housing
7/8"
22.3 MM 1-5/8"
42 MM
3-11/16"
I.D. 7/16" 94 MM
Ø11 MM 11/16" 4-13/16" I.D. 5/16"
18 MM 122.3 MM 5-3/8" Ø8 MM 2-1/4"
I.D. 1/2" 136.8 MM 56 MM
Ø13 MM
45°

O.D. 1-1/2"
Ø38.1 MM
WORKS WITH: BUFFERS 1107-8459-4 HANDLE
MATERIAL: FORGED STEEL FINISH: WELDABLE PRIMER
WEIGHT: 3.8 LBS / 1.72 Kg
