TWISTLOCK PINS
CHASSIS | FLATBED TRAILERS
MODEL 1105-2038-L
MODEL 1105-2038-R
for Trailmobile chassis
1-1/4"
31.8 MM 1/16" 1105-2038-L 1105-2038-R
1.6 MM 3-3/4"
O.D. 2" 95.3 MM
Ø50.8 MM
3-1/8" 45º
79.4 MM
2"
5-1/2" 50.8 MM
I.D. 1/2" 139.7 MM 1105
Ø12.7 MM
O.D. 1-1/2" SUB FOR: PENZ 15-20-XX MATERIAL: FORGED STEEL
Ø38.1 MM
FINISH: PRIMER WEIGHT: 5.3 LBS / 2.4 Kg
MODEL 1105-2039-L
MODEL 1105-2039-R
for Budd & Trailmobile chassis
1-1/4"
31.8 MM 1/16" 1105-2039-L 1105-2039-R 3-3/4"
1.6 MM 95.3 MM
O.D. 2" 27º
Ø50.8 MM 2-1/2"
2"
63.5 MM 50.8 MM
I.D. 1/2"
Ø12.7 MM 3-1/16"
O.D. 1-1/2" 77.8 MM
Ø38.1 MM
SUB FOR: PENZ 15-37-XXF WORKS WITH: BUFFERS 1107-1619 HANDLE
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 4.5 LBS / 2.04 Kg
MODEL 1105-2040-L
MODEL 1105-2040-R
for Fruehauf chassis &
Penz 90-24 Twistlock
1-1/4"
31.8 MM 1105-2040-L 1105-2040-R
4-1/8"
104.8 MM
O.D. 1-3/8" 45º
Ø35 MM
1/4" 2-5/8"
6.4 MM 66.7 MM 2-1/8"
54 MM
I.D. 3/8"
Ø10.3 MM
3-1/4"
O.D. 15/16" 82.6 MM
Ø23.8 MM
SUB FOR: PENZ 15-66-1-XX FITS: PENZ 90-24-XX TWISTLOCKS
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 2.6 LBS / 1.18 Kg
