1105-35
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-2029
1-1/16" for Blair 149/NRS Twistlock
26 MM
MODEL 1105-2029-MOD
O.D. 1-7/16" Modified to fit Buffers 1101-1240-NRS
Ø37.2 MM 2-7/16" Twistlock
62 MM
5-3/4" 3-11/16"
146.3 MM 94 MM
6-5/16"
160.5 MM 2-1/4"
I.D. 1/2"
1105 Ø12.7 MM 56 MM
O.D. 1-3/16"
Ø29.8 MM
SUB FOR: BLAIR 1024 FITS: BUFFERS 1101-3240-NRS & BLAIR 149/NRS TWISTLOCKS
WORKS WITH: BUFFERS 1107-1542-A ROUND HANDLE & 1107-1542-B COLLAR
MATERIAL: STEEL FINISH: PRIMER WEIGHT: 4.03 LBS / 1.83 Kg

MODEL 1105-2036
2"
50.8 MM for Allied & Trailco chassis

3-7/8"
4-1/4" 4-1/4" 98.4 MM
I.D. 1" 108 MM 3/8"-16 TPI 108 MM
Ø26.2 MM thru thread 2-1/4"
7-3/8" 57.2 MM
187.3 MM

O.D. 1-15/16"
Ø49.2 MM SUB FOR: PENZ 15-06 WORKS WITH: BUFFERS 1109-1498 & 1109-1502 RISER BLOCKS
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 8.7 LBS / 3.95 Kg

MODEL 1105-2037
1-1/4"
31.8 MM 1/16" 13/16" for West Lake ML85-2/3 Twistlocks
1.6 MM 20.6 MM (newer body style w/ bushing)*
O.D. 2"
Ø50.8 MM
3/32" 3-3/4"
2.2 MM 7/8" 6-7/16" 95.3 MM
I.D. 1/4" 22.2 MM 163.5 MM 5-13/16"
Ø6.4 MM 147.6 MM 2"
5-7/8"
I.D. 1/4" 149.2 MM I.D. 5/8" 50.8 MM
Ø6.4 MM Ø15.5 MM
O.D. 1-1/2"
Ø38.1 MM
*NOTE: This Pin fits West Lake ML85-2/3 SUB FOR: PENZ 15-143 FITS: WEST LAKE ML85-2/3 TWISTLOCKS
Twistlocks w/ NEWER Body style (w/ bushing). (newer body style w/ bushing)* WORKS WITH: BUFFERS 1107-1269-L/R HANDLES,
Compare against Model 1105-1301 Pin for 1108-1271-L/R LATCHES & 1109-4528 BUSHING MATERIAL: FORGED STEEL
use w/ OLDER Body style (w/o bushing). FINISH: PRIMER WEIGHT: 4.5 LBS / 2.04 Kg

904-696-0010

E-mail: sales@buffersusa.com
1105-35 12/20/23
