P. 142
1105-09
[return to Table of Contents]
INNER PIN ASSEMBLIES
for NON-SCREWDOWN TWISTLOCKS
CHASSIS | FLATBED TRAILERS
MODEL 1105-8700-INNER
8700-INNER PIN ASSEMBLY
CONSISTS OF: SOLD ONLY AS ASSEMBLY:
• 1105-8700-2 PIN Shear Block, Guide Plate, Detent Balls (2),
• 1109-3637-3-H SHEAR BLOCK Spring, Grease Fittings (2), Split Roll Pin,
• 1110-3637-5-H GUIDE PLATE Handle & Bolts are included.
• 1110-4501 DETENT BALLS (2 ea.)
• 1110-4502 DETENT SPRING
• 1110-4503 GREASE FITTINGS (2 ea.) MODEL 1101-8700-KIT
• 1110-4548 SPLIT ROLL PIN
ASSEMBLED AS SHOWN PIN ASSEMBLY for CIMC Housing:
Inner w/ Guide Plate, Latch & Handle
ITEM # QTY. PARTS / DESCRIPTION
1105 1105-8700-INNER Includes Pin, Shear Block,
1 1 Guide Plate, Detent Balls (2), Spring,
8700-INNER WEIGHT: Grease Fittings (2), Split Roll Pin, Assembled
6.6 LBS / 2.99 Kg 2 1 1108-3633-18 Latch
3 1 1110-4667 Latch Pin
8700-KIT WEIGHT: 4 1 1110-4512 Flat Washer
9.06 LBS / 4.11 Kg 5 1 1110-3533-19 Latch Spring
6 1 1110-4513-SS Cotter Pin
7 1 1105-8459-4 Handle
8 1 1110-4767-G8 Hex Bolt
9 1 1110-4511-J Hex Nut (Jam type) w/ Nylon Insert
3/4"
19.5 MM
3-11/16"
94 MM
6-1/4"
2-1/4" 158.5 MM
56 MM
4-11/16"
5-1/2" 119 MM
139 MM
O.D. 1-1/2"
Ø38 MM
904-696-0010
E-mail: sales@buffersusa.com
1105-9 6/16/22
