1105-08
[return to Table of Contents]
INNER PIN ASSEMBLIES
for NON-SCREWDOWN TWISTLOCKS
CHASSIS | FLATBED TRAILERS
MODEL 1105-6428-INNER
1-3/16"
30 MM for Holland GL-726-099-196
Retractable Twistlock
3-11/16"
6-1/4"
158 MM 94 MM
6-7/8" 2-1/4"
O.D. 1-3/8" 175 MM 56 MM
Ø34.8 MM
1105
I.D. 5/8"
Ø16 MM
SUB FOR: HOLLAND GL-726-099-198
SOLD ONLY AS ASSEMBLY: FITS: HOLLAND GL-726-099-196 RETRACTABLE TWISTLOCK
Pin, Shear Block, Grease Fittings (2), Detent WORKS WITH: BUFFERS 1107-6429-KIT HANDLE
Balls (2), Spring & Bushing are included. MATERIAL: STEEL FINISH: PRIMER WEIGHT: 7.38 LBS / 3.35 Kg
904-696-0010
E-mail: sales@buffersusa.com
1105-8 4/1/24
