TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-1131-29
PIN SLEEVE for Buffers 1131,
1206 & 1207 Series Twistlocks
3-7/16"
88 MM

O.D. 2"
Ø51 MM

I.D. 1-9/16" 1105
Ø40 MM
FITS: BUFFERS 1101-1131, 1101-1206 & 1101-1207 SERIES
TWISTLOCKS WORKS WITH: BUFFERS 1105-1131-2 PIN
MATERIAL: FORGED STEEL FINISH: PRIMER
WEIGHT: 0.93 LBS / 0.42 Kg

MODEL 1105-1132-2
13/16"
9/16" 20 MM
15 MM
3-7/8"
97.5 MM
I.D. 5/16" 2-9/16"
I.D. 7/16" Ø7.9 MM 65.5 MM
Ø11 MM 5-3/4" 2-3/8"
145 MM 59.5 MM
6-7/16" 5-3/4"
I.D. 5/8" 164 MM I.D. 5/16" 145 MM
Ø17 MM Ø8 MM

O.D. 1-1/2"
Ø38 MM FITS: BUFFERS 1101-1132 & 1101-1132-OS-R TWISTLOCKS
WORKS WITH: BUFFERS 1107-1133-4 & 1107-1132-4OS HANDLES
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 4.41 LBS / 2 Kg

MODEL 1105-1132-2-MOD
13/16"
9/16" 20 MM Drilled perpendicular to standard*
15 MM

I.D. 5/16" 2-9/16" 3-7/8"
I.D. 7/16" Ø7.9 MM 65.5 MM 97.5 MM
Ø11 MM 5-3/4"
145 MM
6-5/16" 5-3/4" 2-3/8"
I.D. 5/16" 160 MM I.D. 5/8" 145 MM 59.5 MM
Ø8 MM Ø17 MM

O.D. 1-1/2"
Ø38 MM FITS: BUFFERS 1101-1132-OS-R-MOD TWISTLOCK
WORKS WITH: BUFFERS 1107-1133-4 & 1107-1132-4OS HANDLES
*NOTE: This Twistlock Pin is used for SPECIAL MATERIAL: FORGED STEEL FINISH: PRIMER
HANDLE POSITION REQUIREMENTS ONLY. WEIGHT: 4.41 LBS / 2 Kg
