1105-07
[return to Table of Contents]
INNER PIN ASSEMBLIES
for NON-SCREWDOWN TWISTLOCKS
CHASSIS | FLATBED TRAILERS

MODEL 1105-3633-2-INNER-K-HDG
1-3/16"
30 MM
1/16" 2"
1.5 MM 50.5 MM
2-1/4"
56 MM 3-11/16"
2-1/4" 5/16" 94 MM
56 MM 8 MM
1-7/16" 5-7/16"
35.5 MM 138 MM 2-1/4"
O.D. 1-1/2" 6-1/4" 3-11/16" 56 MM
94 MM
Ø38 MM 158.5 MM
I.D. 1/2"
Ø13 MM
1105
FITS: 1101-3633-R-MOD-K-HDG TWISTLOCK
SOLD ONLY AS ASSEMBLY: WORKS WITH: 1107-3633-4-HDG & 1107-8533-4-HDG
Shear Block, Guide Plate, Detent Balls (2), STRAIGHT HANDLES, 1108-3633-18-KIT-HDG LATCH
Spring, Grease Fittings (2) & Split Roll Pin MATERIAL: STEEL FINISH: HOT-DIP GALVANIZED
(fitted onto Pin) are included. WEIGHT: 6.77 LBS / 3.07 Kg

MODEL 1105-3637-INNER-H
3/4"
19.5 MM

3-11/16"
94 MM
4-11/16"
5-1/2"
O.D. 1-1/2" 139 MM I.D. 1/2" 119 MM 2-1/4"
Ø38 MM Ø13 MM 56 MM

FITS: BUFFERS 1101-3136-R/NR, 1101-3137-R/NR,
SOLD ONLY AS ASSEMBLY: 1101-3637-R/NR & 1101-3643-R/NR TWISTLOCKS
Shear Block, Guide Plate, Detent Balls (2), WORKS WITH: 1107-3133-4 & 1107-8533-4 (straight) or
Spring, Grease Fittings (2) & Split Roll Pin 1107-3643-4 & 1107-8543-4 (Bent) HANDLES, 1108-3633-18 LATCH
(fitted onto Pin) are included. MATERIAL: STEEL FINISH: PRIMER WEIGHT: 5.9 LBS / 2.68 Kg

MODEL 1105-3837-INNER
13/16"
20 MM

3-11/16"
94 MM
4-7/8"
5-11/16" 124 MM
O.D. 1-1/2" 143.5 MM I.D. 1/2" 2-1/4"
Ø38 MM Ø13 MM 56 MM

SOLD ONLY AS ASSEMBLY:
Shear Block, Guide Plate, Detent Balls (2), FITS: BUFFERS 1101-3837-R/NR & 1101-3843-R/NR TWISTLOCKS
Spring, Grease Fittings (2) & Split Roll Pin WORKS WITH: 1107-8533-4 (straight) or 1107-8543-4 (bent) HANDLES
(fitted onto Pin) are included. MATERIAL: STEEL FINISH: PRIMER WEIGHT: 6.45 LBS / 2.93 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-7 5/16/24
