1110-04
[return to Table of Contents]
MISC. TWISTLOCK HARDWARE

CHASSIS | FLATBED TRAILERS

MODEL 1110-4501 MODEL 1110-4549 MODEL 1110-4562
DETENT BALL DETENT BALL DETENT BALL
O.D. 7/16"
Ø11 MM
O.D. 3/8" O.D. 5/16"
Ø8 MM
Ø10 MM
SUB FOR: PENZ 16-02
FITS: BUFFERS 1102-1257, 1102-1259,
1102-3259, SCHULZ F26NS, F33NS, SUB FOR: WEST LAKE 0154
SUB FOR: PENZ 16-01 F33SLNS, F66NS, QA12NS, QA15NS, FITS: CMCI, SCHULZ JL-85-1/2/3/4,
WORKS WITH: QA18NS, R318NS, RQ36NS & VK21RT WEST LAKE WL60-4/6, WL60-16,
BUFFERS 1110-4502 SPRING TWISTLOCKS WORKS WITH: WL85-2/3/4/5, WL100-2/3 TWISTLOCKS
FITS: BUFFERS & PENZ TWISTLOCKS BUFFERS 1110-4550 SPRING WORKS WITH: BUFFERS 1110-4577
MATERIAL: CHROME ALLOY MATERIAL: CHROME ALLOY SPRING MATERIAL: CHROME ALLOY
WEIGHT: 0.008 LBS / 3.63 g WEIGHT: 0.012 LBS / 5.44 g WEIGHT: 0.005 LBS / 2.27 g
1110

MODEL 1110-4667-KIT
Kit includes:
LATCH CONVERSION KIT
to Spring Load
1110-3533-19 1110-4512 1110-4513-SS
LATCH SPRING 3/8" FLAT COTTER PIN
WASHER 5/32" x 3/4"

FITS: BUFFERS TWISTLOCKS,
SERIES 3500, 3600, 3700 & 3800
1110-4667 CLEVIS PIN MATERIAL: STEEL
9.5 MM x 125.5 MM Kit components are ALSO sold separately. WEIGHT: 0.2 LBS / 0.09 Kg

MODEL 1110-7361
SPRING

8" 2-13/16"
O.D. Ø13/16" 2-1/32" 25/32"
19/32"

O.D. Ø3/32"
SUB FOR: PENZ 50-18
MATERIAL: STAINLESS STEEL SPRING WIRE
FINISH: ZINC-PLATED WEIGHT: 0.13 LBS / 59 g

904-696-0010
E-mail: sales@buffersusa.com
1110-4 3/20/24
