1110-01
[return to Table of Contents]
TWISTLOCK GUIDE PLATES

CHASSIS | FLATBED TRAILERS

GUIDE PLATES
Length / O.D.
A

Width
B

MODEL 1110-1132-5
shown illustrated

Hole I.D.
1110 C
Height/Thickness
D
MATERIAL: STEEL
FINISH: PRIMER or HOT-DIP GALVANIZED (-HDG)

MODEL A B C D WEIGHT:
1110-1132-5 3-13/16"/Ø97.5mm 2-5/16"/59.5mm 1-9/16"/Ø39mm 5/16"/8mm 0.57 LBS /0.26 Kg
1110-3133-5 3-11/16"/Ø94mm 2-3/16"/56mm 1-9/16"/Ø39mm 5/16"/8mm 0.51 LBS /0.23 Kg
1110-3152-5 3-15/16"/Ø99.5mm 2-5/16"/59.5mm 1-9/16"/Ø39mm 1/4"/6mm 0.44 LBS /0.2 Kg
1110-3532-5 3-13/16"/Ø97.5mm 2-5/16"/59.5mm 1-7/8"/Ø47.5mm 5/16"/8mm 0.51 LBS /0.23 Kg
1110-3533-5 3-11/16"/Ø94mm 2-1/4"/57mm 1-7/8"/Ø47.5mm 5/16"/8mm 0.39 LBS /0.18 Kg
1110-3533-5-HDG 3-11/16"/Ø94mm 2-1/4"/57mm 1-7/8"/Ø47.5mm 5/16"/8mm 0.39 LBS /0.18 Kg
1110-3600-5 4-1/4"/Ø108mm 2-7/16"/61mm 2-1/16"/Ø52mm 7/16"/10mm 0.71 LBS /0.32 Kg
1110-3837-5 3-11/16"/Ø94mm 2-1/4"/57mm 1-7/8"/Ø47.5mm 5/16"/7mm 0.4 LBS /0.18 Kg

904-696-0010
E-mail: sales@buffersusa.com
1110-1 8/31/20
