1110-03
[return to Table of Contents]
TWISTLOCK SPRINGS

CHASSIS | FLATBED TRAILERS

MODEL 1110-3706-19L 2-1/8" / 54 MM I.D. 13/32" MODEL 1110-3706-19R
Ø10.5 MM
LATCH SPRING O.D. 5/64" LATCH SPRING
Ø2 MM

2-1/8"
54 MM

1110-3706-19-L is shown dimensioned. 1110-3706-19R is the mirror opposite.
FITS: BUFFERS TWISTLOCKS: 1131, 1206, 1207 series, 1217, 3206, 3406, 3407, 3706, 3707 & 3817
MATERIAL: SS SPRING WIRE FINISH: SELF-COLOR WEIGHT: 0.02 LB / 9 g
1110

MODEL 111 MODEL 1110-4502
0-3533-19
LATCH SPRING DETENT SPRING
Ø1/16"

Ø3/8"

1-1/2"
9/16"
Ø14.5 MM FITS: BUFFERS TWISTLOCKS
WORKS WITH: BUFFERS 1110-4501 DETENT BALL
MATERIAL: SPRING STEEL WEIGHT: 0.008 LB / 3.63 g
15/32"
9/16"
14 MM 12 MM MIN. 2 LOOPS
AS SHOWN
7/8"
22 MM MODEL 1110-4550
Ø1/16"
1-1/2" DETENT SPRING
9/32" 38 MM
7.25 MM
Ø3/8"
130° 1-5/16"
MATERIAL: SUB FOR: PENZ 50-20
SS SPRING WIRE FITS: BUFFERS 1102-1257, 1102-1259, 1102-3259,
FINISH: SCHULZ F26NS, F33NS, F33SLNS, F66NS, QA12NS,
I.D. 15/32" QA15NS, QA18NS, R318NS, VK21RT & RQ36NS TWISTLOCKS
Ø12 MM SELF-COLOR WORKS WITH: BUFFERS 1110-4549 DETENT BALL
WIRE O.D. 3/32" WEIGHT: MATERIAL: SPRING STEEL WEIGHT: 0.008 LB / 3.63 g
Ø2.5 MM 0.02 LB / 9 g

MODEL 1110-4577 Ø1.5 MM O.D. WIRE w/ MODEL 1110-4581
Ø1/16" 4-5 LOOPS, CLOSED
DETENT SPRING & GROUND ENDS O.D. 1/16" DETENT SPRING
Ø1.5 MM
Ø9/32"
1/2"
SUB FOR: WEST LAKE 1226
FITS: CMCI, SCHULZ JL-85-1/2/3/4,
WEST LAKE WL60-4/6, WL60-16, 5/8" FITS: HOLLAND TWISTLOCKS:
WL85-2/3/4/5, WL100-2/3 TWISTLOCKS 15.5 MM GL-726-099-195 (NON-RETRACTABLE)
WORKS WITH: BUFFERS & GL-726-099-196 (RETRACTABLE)
1110-4562 DETENT BALL MATERIAL: SPRING STEEL
MATERIAL: SPRING STEEL O.D. 9/32" FINISH: SELF-COLOR
Ø7.5 MM
WEIGHT: 0.003 LB / 1.45 g WEIGHT: 0.003 LB / 1.45 g
