1109-08
[return to Table of Contents]
HOUSING

for DROP-IN TWISTLOCKS
CHASSIS

MODEL 1109-3270-1
O.D. 3-7/8"
Ø98 MM HOUSING

5/8" 1-1/4"
16 MM 32 MM
2-1/4"
57 MM
3-15/16"
100 MM
2-1/16"
O.D. 2-1/4" 52 MM
Ø57 MM
I.D. 1-1/2"
1109 Ø39 MM O.D. 3-3/16"
Ø81 MM

WORKS WITH: BUFFERS 1102-3270-LH/RH, 1102-3290-LH/RH DROP-IN TWISTLOCKS
MATERIAL: CAST STEEL FINISH: PRIMER WEIGHT: 2.64 LBS / 1.2 Kg

904-696-0010
E-mail: sales@buffersusa.com
1109-8 10/27/22
