1105-39
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

NOTE: This Pin is used on the Blair 149/2NR Twistlock w/ MODEL 1105-2445
FLAT Handle. Use model 1105-1540 Pin for ROUND Handle. for Blair 149/2NR Twistlock
(w/ Flat Handle)
1-1/4"
31.8 MM
3-3/4"
95.3 MM
2-1/2"
63.5 MM
3/8" 3/8" 2"
9.7 MM 5-3/16" 9.7 MM 50.8 MM
130.7 MM 1105

O.D. 1-15/32" SUB FOR: BLAIR 1026 (for Flat Handle) FITS: BLAIR 149/2NR TWISTLOCK (w/ Flat Handle)
Ø37.3 MM WORKS WITH: BUFFERS 1107-1541 FLAT HANDLE MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 3.96 LBS / 1.8 Kg

2" SPECIAL ORDER ONLY MODEL 1105-2476
50.8 MM for Fruehauf chassis

O.D. 2-1/4" 3-7/8"
Ø57.2 MM 1/4" 98.4 MM
4-1/8"
6.4 MM 104.8 MM 2-1/4"
6" 57 MM
I.D. 3/4" 152.4 MM
Ø19.5 MM

O.D. 1-3/4"
Ø44.5 MM SUB FOR: PENZ 15-51 WORKS WITH: BUFFERS 1107-1394 HANDLE paired w/
1110-2477 CLEVIS BOLT + 1110-4551-SS COTTER PINS (2 pcs.), 1109-1504 RISER BLOCK
COMPARE AGAINST MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 6.7 LBS / 3.04 Kg
PIN 1105-2853

MODEL 1105-2545
1-1/4"
31.8 MM for Penz 90-09 Twistlock
1/16"
1.6 MM (newer style w/ Split Pin)
O.D. 2" I.D. 3/8"
Ø50.8 MM Ø10.3 MM
I.D. 1/4" 3-3/4"
Ø6.4 MM 1-1/16"
1-5/8" 7-1/2" 27 MM 95.3 MM
41.3 MM 190.5 MM
6-3/8" 2"
161.9 MM 50.8 MM
I.D. 9/16"
Ø15.1 MM

O.D. 1-1/2"
Ø38.1 MM SUB FOR: PENZ 15-137 FITS: PENZ 90-09-XX TWISTLOCKS (newer style w/ Split Pin)
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 4.94 LBS / 2.24 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-39 3/9/23
