1105-41
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-2751

1-1/4"
31.8 MM 1/16"
1.6 MM
O.D. 2"
Ø50.8 MM 3-3/4"
5/32" 95.3 MM
4 MM
I.D. 3/8" 4-15/16"
Ø9.5 MM 2-5/16" 125.4 MM 5-7/16" 2-5/16" 2"
58.7 MM 138.1 MM 58.7 MM 50.8 MM
I.D. 1/2" 1105
Ø13 MM
O.D. 1-1/2"
Ø38.1 MM
SUB FOR: PENZ 15-104 MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 4.2 LBS / 1.91 Kg

MODEL 1105-2836

1-1/4"
31.8 MM 1/16"
1.6 MM
O.D. 2"
Ø50.8 MM 3-3/4"
2-7/8" 95.3 MM
73 MM
5-3/4" 2"
I.D. 1/2" 146.1 MM 50.8 MM
Ø13.5 MM

O.D. 1-1/2"
Ø38.1 MM
SUB FOR: PENZ 15-83F MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 4.2 LBS / 1.91 Kg

MODEL 1105-2837
for West Lake 1760 Twistlock
1-1/4"
31.8 MM 1/16"
1.6 MM 1-3/16"
30.2 MM
O.D. 2"
Ø50.8 MM 3-3/4"
I.D. 7/16" 2-15/16" 95.3 MM
4-7/16" Ø11.9 MM 74.6 MM
112.7 MM 5-1/4" 2"
133.4 MM
50.8 MM
I.D. 1/2"
Ø13.5 MM
O.D. 1-1/2"
Ø38.1 MM
SUB FOR: PENZ 15-151F, WEST LAKE 1780 FITS: WEST LAKE 1760 TWISTLOCK
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 3.7 LBS / 1.68 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-41 10/25/23
