5004-02

UNLOCKING POLE
®
EXTENDABLE, QUICK-COUPLING TYPE
w/ PUSH-BUTTON

5004-AP-Q-2.6
5004-APB-Q-2.2-25 5004-APB-Q-2.2-23 EXTENSION PIECE
QUICK-COUPLING QUICK-COUPLING
STARTER POLE w/ STARTER POLE w/
AH-25 HEAD AH-23 HEAD 5004-AP-QB-MALE

L = 9' / 2.6M =
ONE MORE TIER

L L

5004 5004-AP-QB-FEMALE

ITEM MODEL TYPE LENGTH WEIGHT REACH
1 5004-APB-Q-2.2-23
2 5004-APB-Q-2.2-25 STARTER 2.2 M 7' 2 Kg 4.4 LBS 2 HIGH
3 5004-APB-Q-5.0-23 STARTER
4 5004-APB-Q-5.0-25 5 M 16' 3 Kg 6.6 LBS 3 HIGH
5 5004-APB-Q-5.4-23
6 5004-APB-Q-5.4-25 STARTER 5.4 M 18' 3.4 Kg 7.5 LBS 3 HIGH
7 5004-APB-Q-7.7-23
8 5004-APB-Q-7.7-25 STARTER 7.9 M 26' 4.9 Kg 11 LBS 4 HIGH

9 5004-AP-Q-2.6 EXTENSION 2.6 M 9' 2.9 Kg 6.4 LBS ONE TIER MORE
1 ea. ITEM 1
10 5004-APB-Q-KIT/APM-23 SET 3 ea. ITEM 9 10.7 Kg 23.6 LBS 2 – 5 HIGH
1 ea. ITEM 2
11 5004-APB-Q-KIT/APM-25 SET 10.7 Kg 23.6 LBS 2 – 5 HIGH
3 ea. ITEM 9
5 HIGH

4 HIGH
APB-Q-5.0 +
2 x AP-Q-2.6 3 HIGH

APB-Q-5.0 +
AP-Q-2.6 2 HIGH
APB-Q-5.0 OR APB-Q-2.2
APB-Q-2.2 +
AP-Q-2.6

MATERIAL: AGE-HARDENED ALUMINUM TUBE / STAINLESS STEEL ACTUATOR HEAD.

®
904-696-0010 FAX: 904-696-0019
E-mail: sales@buffersusa.com
5004-2 11/1/19
