5001-01
20' STORAGE FLATRACK
®
8-BIN CAPACITY
MODEL 5001-E-17
ISO CORNER CASTING YELLOW / BLACK
FLUORESCENT MARKING
SECURING POINT FOR BIN
FORKLIFT POCKET
1,091 MM
3' 7"
2,050 MM 2,259 MM
6' 8-1/2" 7' 31/32"
5,853 MM 2,438 MM
19' 2-7/16" 8'
6,058 MM 5001
19' 10-1/2"
DESIGNED FOR BIN E-16
SIZE: 52" L x 34-1/4" W x 31" H
OWNER TO GIVE CONTAINER NUMBER.
CSC APPROVED.
TO BE LIFTED WITH 20' CONTAINER SPREADER.
MAX. GROSS WEIGHT: 20,000 Kg / 44,100 LBS
TARE: 1,550 Kg / 3,419 LBS
CAPACITY: 8 EA. E-16 BINS
MAX 17,100 Kg PRODUCTS INSIDE THE BINS
MAX 250 PCS C5AM-DF PER BIN = 2,000 / RACK
MATERIAL: MILD STEEL
FINISH: HOT-DIP GALVANIZED (HDG)
®
904-696-0010 FAX: 904-696-0019
E-mail: sales@buffersusa.com
5001-1 7/5/18
