5007-08

TURNBUCKLE
®
HOOK & JAW

MODEL 5007-M5-50-EXT/J
STANDARD

32.5 MM 75 MM
1-9/32" 2-15/16"

65 MM
2-9/16" Ø 30 MM
1-3/16"

LEFT RIGHT
THREAD THREAD
4 5 3 1 7 6 2
TO TIGHTEN, TURN BODY
COUNTER-CLOCKWISE
5007

42 MM 30 MM
1-21/32" 440 MM 460 MM 1-3/16"
17-5/16" 18-1/8"
940 MM – 1,410 MM
37" – 55-1/2"

ITEM QTY MODEL APM # DESCRIPTION WEIGHT
1 1 5007-M5-50-EXT-BODY BODY 4.35 Kg / 9.6 LBS
2 1 5007-M5-HOOK-H-SIDE HOOK w/ SHANK 3.83 Kg / 8.45 LBS
RIGHT-HAND THREAD, ACME 32-6 MM
3 1 5007-M5-JAW-J-SIDE JAW w/ SHANK 3.83 Kg / 8.45 LBS
LEFT-HAND THREAD, ACME 32-6 MM
4 & 5 1 5007-TB-50-TGN 351416 TOGGLE PIN w/ SPRING & STOP PIN 0.71 Kg / 1.57 LBS
6 1 5007-M5/M7-LN LOCK NUT 0.18 Kg / 0.4 LBS
RIGHT-HAND THREAD, ACME 32-6 MM
7 1 5007-M5/FLX-SW SPRING WASHER 0.06 Kg / 0.13 LBS

MIN. B.L.: 50 M. TON
MATERIAL: STEEL
FINISH: HOT-DIP GALVANIZED (HDG)
WEIGHT: 12.29 Kg / 27.1 LBS

®
904-696-0010 FAX: 904-696-0019
E-mail: sales@buffersusa.com
5007-8 8/7/18
