1211-09
[return to Table of Contents]
CONTAINER SIDE PANEL
STAINLESS STEEL (EXTERIOR), 2-RIB
REEFER CONTAINERS

3-15/16" / 100 MM
4-3/4" / 120 MM B MODEL 1211-7629
7-1/2" EXTERIOR STARTER SIDE PANEL
190 MM (Front End), Stainless Steel, 2-Rib
3/4"
20 MM
10-13/16"
275 MM
11-13/16" 5-7/8"
300 MM 150 MM 7-1/16"
180 MM 1211
2-3/4" 15/16"
70 MM 24.2 MM
4-3/4" 1-3/16" 3/16"
120 MM 30 MM 5 MM 3/64"
98-1/16" 1 MM
2,490 MM SECTION A-A

3/4"
20 MM

DETAIL B
3/4"
20 MM SUB FOR: CIMC SA07-076-U0-QD FITS: CIMC 40' x 96" HC REEFER
LENGTH: 98-1/16" / 2,490 MM THICKNESS: 3/64" / 1 MM
MATERIAL: STAINLESS STEEL FINISH: SELF-COLOR
23-13/16" WEIGHT: 25 LBS / 11.3 Kg
605 MM
A A

904-696-0010
E-mail: sales@buffersusa.com
1211-9 3/16/21
