1211-14
[return to Table of Contents]
CONTAINER ROOF PANELS
STAINLESS STEEL
REEFER CONTAINERS

SPECIAL ORDER ONLY MODEL 1211-6239
A A
EXTERIOR ROOF PANEL
Stainless Steel, 3-Rib
1"
25 MM

1211
15-9/16"
395 MM
TYP 7-3/4"
198 MM
1-15/16"
93-5/16" 50 MM
2,370 MM TYP
3"
SECTION A-A 1/4" 76 MM
6 MM TYP

1"
25 MM SUB FOR: MAERSK 7772603A FITS: MCIQ 40' x 96" HC REEFER
LENGTH: 93-5/16" / 2,370 MM THICKNESS: 1/32" / 0.8 MM
MATERIAL: STAINLESS STEEL FINISH: SELF-COLOR
46-5/8" WEIGHT: 38.8 LBS / 17.6 Kg
1,185 MM

A A MODEL 1211-6455
B
EXTERIOR ROOF END PANEL
Stainless Steel, 1-Rib
1"
25 MM 5-13/16"
147 MM
1-15/16" 1-3/16" 1/4"
50 MM 30 MM 6 MM

SECTION A-A
3" 1-9/16"
76 MM 40 MM
93-5/16"
2,370 MM 1-3/4"
45 MM
5-13/16" 1"
147 MM 25 MM

5-7/8"
150 MM

DETAIL B
1"
25 MM
SUB FOR: MAERSK 7772210 FITS: MCIQ 40' x 96" HC REEFER
LENGTH: 93-5/16" / 2,370 MM THICKNESS: 1/32" / 0.8 MM
MATERIAL: STAINLESS STEEL FINISH: SELF-COLOR
15-5/16" WEIGHT: 12.8 LBS / 5.8 Kg
389.5 MM

904-696-0010
E-mail: sales@buffersusa.com
1211-14 3/3/23
