1211-13
[return to Table of Contents]
CONTAINER SIDE PANEL
STAINLESS STEEL (EXTERIOR), 5-RIB
REEFER CONTAINERS
A A MODEL 1211-6454
B
EXTERIOR SIDE PANEL
Stainless Steel, 5-Rib
3/4"
19 MM
3-15/16"
100 MM
9-1/16"
230 MM 1-1/4" 1211
TYP 32.2 MM
TYP
1-7/16"
3/16" 36 MM
4.5 MM TYP
98-13/16"
2,510 MM SECTION A-A
9/16"
14 MM
DETAIL B
3/4" SUB FOR: MAERSK 7162302 FITS: MCIQ 40' x 96" HC REEFER
19 MM
LENGTH: 98-13/16" / 2,510 MM THICKNESS: 3/64" / 1.2 MM
MATERIAL: STAINLESS STEEL FINISH: SELF-COLOR
WEIGHT: 58.2 LBS / 26.4 Kg
43-9/16"
1,106 MM
904-696-0010
E-mail: sales@buffersusa.com
1211-13 3/17/21
