1208-09
[return to Table of Contents]
STEEL SIDE RAILS
BOTTOM
REEFER CONTAINERS

MODEL 1208-6217 MODEL 1208-6218
1" MODEL 1208-6217-19 5/32" MODEL 1208-6218-19
25.4 MM 4 MM
BOTTOM RAIL, Lower BOTTOM RAIL, Upper
FITS: MCIQ/TRITON 40' HC FITS: MCIQ/TRITON 40' HC
3-3/4"
5-5/16" MATERIAL: CORTEN STEEL 5-1/8" 96 MM MATERIAL: CORTEN STEEL
5/32" 135 MM FINISH: PRIMER 130 MM FINISH: PRIMER 1208
4 MM
1208-6217 1208-6218
SUB FOR: MAERSK 7420014 & 7460817 SUB FOR: MAERSK 7460716
LENGTH: 38' 10" / 11,838 MM LENGTH: 38' 10" / 11,838 MM
1" WEIGHT: 134.7 LBS / 61.1 Kg 1-9/16" WEIGHT: 128.6 LBS / 58.3 Kg
25.4 MM 1208-6217-19 40 MM 1208-6218-19
LENGTH: 19' / 5,791 MM LENGTH: 19' 5" / 5,918 MM
WEIGHT: 67 LBS / 30.4 Kg WEIGHT: 64.3 LBS / 29.1 Kg

BOTTOM RAILS
A
MODEL # A B C WEIGHT SUB FOR
3/16" 1208-7647 1" / 25 MM 4-1/8" / 105 MM 1" / 25 MM 35 LBS / 15.9 Kg CIMC 02-013
4.5 MM B 1208-7648 1" / 25 MM 5-1/16" / 128 MM 1" / 25 MM 37 LBS / 16.8 Kg CIMC 02-007, 02-011
1208-7649 1" / 25 MM 5-7/8" / 150 MM 1" / 25 MM 41 LBS / 18.6 Kg CIMC 02-012
1208-7650 1-9/16" / 40 MM 5-7/8" / 150 MM 1" / 25 MM 45 LBS / 20.4 Kg CIMC 02-014
C
FITS: CIMC 40' REEFER LENGTH: 9' 10-1/8" / 3,000 MM
MATERIAL: CORTEN STEEL FINISH: WELDABLE PRIMER

3-15/16" MODEL 1208-7651 MODEL 1208-7652
100 MM BOTTOM RAIL BOTTOM RAIL

4-3/8"
111 MM 6-3/16"
157 MM

SUB FOR: CIMC 07-012 SUB FOR: CIMC 07-013
5/32" FITS: CIMC 40' REEFER FITS: CIMC 40' REEFER
4-13/16" 4 MM LENGTH: 9' 10-1/8" / 3,000 MM LENGTH: 9' 10-1/8" / 3,000 MM
122 MM MATERIAL: CORTEN STEEL 1-3/8" 5/32" MATERIAL: CORTEN STEEL
4 MM
1-3/8" FINISH: WELDABLE PRIMER 35 MM FINISH: WELDABLE PRIMER
35 MM WEIGHT: 30.1 LBS / 13.7 Kg WEIGHT: 32.1 LBS / 14.6 Kg

MODEL 1208-7705-18.7
BOTTOM RAIL
Upper

4-1/4"
6-5/32" 108 MM
156 MM
FITS: CIMC 40' REEFER
LENGTH: 18' 8" / 5,690 MM
5/32" MATERIAL: CORTEN STEEL
4 MM FINISH: WELDABLE PRIMER
1-13/32" WEIGHT: 62.16 LBS / 28.2 Kg
36 MM

904-696-0010
E-mail: sales@buffersusa.com
1208-9 3/8/21
