1209-02
[return to Table of Contents]
FRONT BOTTOM RAIL

& REAR DOOR SILLS
REEFER CONTAINERS

MODEL 1209-6443
SUB FOR: MAERSK 7133302 FITS: MCIQ 40' REEFER
LENGTH: 83-5/8" / 2,124 MM FRONT BOTTOM RAIL
MATERIAL: CORTEN STEEL FINISH: PRIMER Outer
WEIGHT: 107.2 LBS / 48.6 Kg

1-1/2"
I.D. 11/16" 38 MM
Ø17.5 MM
1209 x 7 HOLES 1-9/16"
3-13/16" 75-9/16" 2-5/8"
96.9 MM 1,919.3 MM 66 MM 39.7 MM
18-1/16"
13/16"
2-1/16" 458.8 MM
53.4 MM 20 MM
14-11/16" 3/16"
372.5 MM 4.6 MM
3/16" 83-1/4"
4.8 MM 2,114.6 MM 3/16" 6-1/4"
4.8 MM 158 MM

MODEL 1209-6460
REAR DOOR SILL
ASSEMBLY
FRONT VIEW REAR VIEW
I.D. 2-1/8"
Ø55 MM x 2 HOLES
I.D. 1/4"
Ø6.73 MM
x 17 HOLES 1-9/16"
40 MM 3-1/4"
81.8 MM
6-5/16"
160 MM
91-15/16" 14-1/2" 1-3/16"
2,335 MM 368 MM 30 MM

SUB FOR: MAERSK 7141610 FITS: MCIQ 40' REEFER MODEL MQRS-40HS-251B LENGTH: 91-15/16" / 2,335 MM
MATERIAL: CORTEN STEEL FINISH: PRIMER WEIGHT: 119 LBS / 53.98 Kg

MODEL 1209-6806
REAR DOOR SILL
Vertical Beam

1-11/16"
2-7/8" 43 MM
73 MM 1/4"
4-1/16" 5-3/4" 6 MM
103 MM 147 MM
7-7/8" 3-7/16"
200 MM 88 MM 2-5/8"
90-1/16" 66.5 MM
2,287 MM

SUB FOR: CIMC EF09-B210-C0 FITS: CIMC 40' x 96" REEFER LENGTH: 90-1/16" / 2,287 MM
MATERIAL: CORTEN STEEL FINISH: PRIMER WEIGHT: 54.2 LBS / 24.58 Kg

904-696-0010
E-mail: sales@buffersusa.com
1209-2 7/19/21
