1208-06
[return to Table of Contents]
STEEL SIDE RAILS
BOTTOM
DOMCON CONTAINERS

MODEL 1208-7935 MODEL 1208-8135
BOTTOM SIDE RAIL BOTTOM SIDE RAIL
Main End Section
2-1/8"
8-9/16"
15/16"
54 MM 15/16" 23 MM 217 MM
24 MM
1208 3-1/4"
82 MM
5/32"
4 MM 8-3/8"
213 MM
5/32" 1/8"
4 MM
12" 3 MM
305 MM 11-7/8"
302 MM
3-1/2"
89 MM
1-1/4"
2-1/2" 1-3/16" 9-7/16" 32 MM
63 MM 30 MM 240 MM

SUB FOR: CIMC AD53-0103B-8,
J.B. HUNT 31921 & SINGAMAS QPH-200001 SUB FOR: CIMC AD53-0103F-14
FITS: CIMC, SINGAMAS 53' / J.B. HUNT FITS: CIMC 53' / J.B. HUNT
LENGTH: 19' 5-1/16" / 5,920 MM LENGTH: 5' 10-15/16" / 1,802 MM
MATERIAL: CORTEN STEEL FINISH: PRIMER MATERIAL: CORTEN STEEL FINISH: PRIMER
WEIGHT: 148.2 LBS / 67.22 Kg WEIGHT: 52 LBS / 23.6 Kg

MODEL 1208-8976
BOTTOM RAIL, Front
Rectangular Tubing

One side is 3mm
longer at each end.
1/16"
2.3 MM 3-15/16"
100 MM

82-9/16"
1-15/16" 2,097 MM
50 MM
1/8" 1/8" / 3 MM 1/8" / 3 MM
3 MM

SUB FOR: SINGAMAS 53-302001
FITS: SINGAMAS 53' / HUB
MATERIAL: CORTEN STEEL FINISH: WELDABLE PRIMER
WEIGHT: 23.9 LBS / 10.84 Kg

904-696-0010
E-mail: sales@buffersusa.com
1208-6 12/14/21
