1205-03
[return to Table of Contents]
FRONT CORNER POSTS
NOTCHED
DOMCON CONTAINERS

MODEL 1205-6906-L MODEL 1205-6906-R
FRONT CORNER POST FRONT CORNER POST
Curbside Roadside

1205

3-5/8" 3-5/8"
92 MM 92 MM
3-5/8" 3-5/8"
92 MM 92 MM

114" 114"
2,897 MM 2,897 MM

2-3/4" 2-3/4"
70 MM 70 MM
12-1/4" 12-1/4"
311 MM 7-15/16" 7-15/16" 311 MM
202 MM 202 MM
3-15/16" 3-15/16"
100 MM 100 MM
FRONT FRONT
SIDE SIDE

1-9/16"
2-1/16" 40 MM
53 MM
1-15/16"
50 MM
1/8"
3.2 MM 1-3/16"
6-3/4" 30 MM 1-15/16"
172 MM SIDE 50 MM SIDE
FRONT FRONT
8-7/8"
225 MM 9-1/16" 3-7/16" R is mirror of L
230 MM 87 MM
12-1/2"
317 MM

SUB FOR: JINDO AD0202-3110 FITS: 48' & 53' w/ 107" DOOR OPENING
LENGTH: 114" / 2,896 MM MATERIAL: CORTEN STEEL
FINISH: PRIMER WEIGHT: 84 LBS / 38.1 Kg

904-696-0010
E-mail: sales@buffersusa.com
1205-3 12/8/21
