CONTAINER ROOF PANELS

STAINLESS STEEL
REEFER CONTAINERS

MODEL 1211-7637
A B A
EXTERIOR INTERMEDIATE ROOF PANEL
Stainless Steel, 1-Rib
1-1/8"
29 MM 24-5/16"
617.5 MM
3/16"
15/16"
1211 24.2 MM 5 MM

1-3/16" 1/32"
30 MM 0.8 MM
SECTION A-A
93-11/16"
2,380 MM

1-1/8"
29 MM
DETAIL B

1-1/8" SUB FOR: CIMC RA02-017-U0-QD
29 MM
FITS: CIMC 40' x 96" HC REEFER
LENGTH: 93-11/16" / 2,380 MM THICKNESS: 1/32" / 0.8 MM
MATERIAL: STAINLESS STEEL FINISH: SELF-COLOR
48-5/8" WEIGHT: 39 LBS / 17.7 Kg
1,235 MM

A A
= = MODEL 1211-8958
B
B EXTERIOR MAIN ROOF PANEL
Stainless Steel, 4-Rib
11-15/16" 1-1/8"
304 MM 28 MM
5-15/16"
151.5 MM 5-15/16"
3/16" 3/16" 151.5 MM
4 MM 4 MM

3/16" SECTION A-A 1/32"
4 MM 0.8 MM
92-1/2" 11-15/16" 11-15/16" 11-15/16" 7/16"
2,350 MM 304 MM 304 MM 304 MM 15 MM
1/32"
0.8 MM

7/16" 3/16" 1-3/8"
15 MM 4.8 MM 36 MM
SECTION B-B DETAIL C

SUB FOR: MAERSK 7560100-C FITS: MCIQ REEFER
LENGTH: 92-1/2" / 2,350 MM THICKNESS: 1/32" / 0.8 MM
5-31/32" MATERIAL: STAINLESS STEEL FINISH: SELF-COLOR
5-15/16" C 47-3/4" 151.5 MM WEIGHT: 35.05 LBS / 15.9 Kg
151.5 MM 1,215 MM
