1106-15
[return to Table of Contents]
PINLOCK PINS

CHASSIS

MODEL 1106-7357 MODEL 1106-8176

1106

Ø3/8" 3/4"

Ø5/8"

1/2" Ø1-1/4"
Ø3/8" 1-3/4"
6-1/8" Ø1-7/8" 4"
10-1/4" 8-1/2"

SUB FOR: PENZ 30-38
FOR USE ON: SEALAND CHASSIS SUB FOR: PENZ 30-14
MATERIAL: FORGED STEEL FINISH: PRIMER MATERIAL: FORGED STEEL FINISH: PRIMER
WEIGHT: 7.45 LBS / 3.38 Kg WEIGHT: 3.1 LBS / 1.41 Kg

MODEL 1106-8706
I.D. 9/32"
Ø7 MM

Use with 1109-8705 Reducing Sleeve
(see catalog pg. 1109-9)

45° 2-1/2"
I.D. 5/8" 63.5 MM
Ø16.5 MM

O.D. 1" 1/2" 1/8"
Ø25 MM 12.5 MM 3 MM @ 45°
5-1/4"
O.D. 1-5/16" 133.8 MM
Ø32.5 MM

USE WITH: BUFFERS 1109-8705 REDUCING SLEEVE
WORKS WITH: BUFFERS 1103-1175 & 1103-1213 PINLOCKS
MATERIAL: CAST STEEL FINISH: PRIMER
WEIGHT: 1.39 LBS / 0.63 Kg

904-696-0010
E-mail: sales@buffersusa.com
1106-15 11/8/22
