SAND SHOE AXLES & LOCKING KITS
CHASSIS & TRAILERS:
AUTO / DRY VAN / FLATBED / REEFER VAN

MODEL 1002-1303-KIT-F MODEL 1002-1304-KIT
HEAVY DUTY 8-13/16" SOLID
8-1/2" w/ Welded Cap 224 MM
216 MM
7-1/4" O.D. 1-7/8"
7-5/8" O.D. 1-7/8" Ø48 MM
1002 193 MM Ø48 MM 185 MM
Includes 1002-1303 Axle
w/ 1002-1360-KIT Locking Kit I.D. 3/8" I.D. 3/8" Includes 1002-1304 Axle
I.D. Ø7/16" supplied fitted as shown Ø9.5 MM Ø9.5 MM w/ 1002-1460-KIT Locking Kit
11 MM 1.9" O.D. x 1.5" I.D. (48 x 38 MM) supplied loose as shown
SUB FOR: HOLLAND LG0204-04 (Axle) & 50616041 (Axle Kit),
SUB FOR: HOLLAND 50616040, PENZ 06-411 MATERIAL: PENZ 06-431 MATERIAL: 1-7/8" SOLID STEEL
1-1/2" SCH 80 TUBE FINISH: PRIMER WEIGHT: 2.9 LBS / 1.32 Kg FINISH: PRIMER WEIGHT: 6.88 LBS / 3.12 Kg

MODEL 1002-1305-KIT-F MODEL 1002-1407-KIT-F
STANDARD DUTY STANDARD DUTY
8-7/8" w/ Flared End 8-1/2" w/ Welded Cap
225 MM 216 MM
7-7/16" O.D. 1-7/8" 7-5/8" O.D. 1-7/8"
188 MM Ø48 MM 193 MM Ø48 MM
Includes 1002-1407 Axle
Includes 1002-1305 Axle w/ 1002-1360-KIT Locking Kit
w/ 1002-1360-KIT Locking Kit supplied fitted as shown
I.D. Ø7/16" supplied fitted as shown I.D. Ø7/16" 1.9" O.D. x 1.61" I.D. (48 x 41 MM)
11 MM 1.9" O.D. x 1.61" I.D. (48 x 41 MM) 11 MM
SUB FOR: PENZ 06-404 MATERIAL: 1-1/2" SCH 40 TUBE SUB FOR: HOLLAND 50616043, PENZ 06-410 MATERIAL:
FINISH: PRIMER WEIGHT: 2.03 LBS / 0.92 Kg 1-1/2" SCH 40 TUBE FINISH: PRIMER WEIGHT: 2.12 LBS / 0.96 Kg

SPECIAL ORDER MODEL 1002-1736-KIT MODEL 1002-2440-KIT-F
SOLID HEAVY DUTY
15-7/8" / 403 MM
8-7/8" w/ Flared End
14-1/16" / 358 MM 225 MM
7-3/8"
O.D. 1-7/8" 187 MM O.D. 1-7/8"
Ø48 MM
Ø48 MM
Includes 1002-1736 Axle
I.D. 3/8" I.D. 3/8" w/ 1002-1460-KIT Locking Kit Includes 1002-2440 Axle
Ø9.5 MM Ø9.5 MM supplied loose as shown w/ 1002-1360-KIT Locking Kit
I.D. Ø7/16" supplied fitted as shown
SUB FOR: HOLLAND LG0204-01, PENZ 06-430 11 MM 1.9" O.D. x 1.5" I.D. (48 x 38 MM)
WORKS WITH: 1001-1791 DOLLY WHEEL & 1001-1737
DOLLY WHEEL FOOT MATERIAL: 1-7/8" SOLID STEEL SUB FOR: HOLLAND 50616042, PENZ 06-405 MATERIAL:
FINISH: PRIMER WEIGHT: 13.1 LBS / 5.94 Kg 1-1/2" SCH 80 TUBE FINISH: PRIMER WEIGHT: 2.7 LBS / 1.22 Kg

MODEL 1002-2775-KIT-P SPECIAL ORDER MODEL 1002-2896-KIT-F
8-3/8" SOLID w/ Welded Cap STANDARD DUTY w/ Welded Cap
213 MM
7-1/2"
190 MM 15-3/8"
391 MM
14-1/2" O.D. 1-7/8"
O.D. 1-7/8" 368 MM Ø48 MM
Ø48 MM Includes 1002-2775 Axle Includes 1002-2896 Axle
w/ 1002-1460-A Roll Pin w/ 1002-1360-KIT Locking Kit
I.D. 3/8" & 1002-1460-B Washer supplied fitted as shown
Ø9.5 MM supplied attached as shown I.D. Ø7/16" / 11 MM 1.9" O.D. x 1.61" I.D. (48 x 41 MM)
SUB FOR: PENZ 06-441 MATERIAL: 1-7/8" SOLID STEEL SUB FOR: PENZ 06-420 MATERIAL: 1-1/2" SCH 40 TUBE
FINISH: PRIMER WEIGHT: 6.95 LBS / 3.15 Kg FINISH: PRIMER WEIGHT: 3.6 LBS / 1.63 Kg
