P. 133
1104-05
[return to Table of Contents]
BOLSTER COMPONENTS
CHASSIS
MODEL 1104-7165
FRONT BOLSTER
CENTER PLATE
SUB FOR: HYUNDAI 20003965
MATERIAL: A27 STEEL PLATE
FINISH: WELDABLE BLACK PRIMER
WEIGHT: 15 LBS / 6.8 Kg
1104
35-3/4" / 908 MM
21-7/8" / 810 MM 1-1/8"
I.D. 1-1/16" 4-3/8" I.D. 5/16" 37 MM
Ø27 MM x 3 HOLES 111.5 MM Ø8.5 MM x 4 HOLES
4-1/4" 6-5/16" 6-7/8"
109 MM 174 MM
161 MM
3-7/16"
87 MM
3-3/4" 2"
95 MM 5 MM
12" / 304 MM
904-696-0010
E-mail: sales@buffersusa.com
1104-5 11/15/19
