1102-12
[return to Table of Contents]
TWISTLOCKS – DROP-IN TYPE
90° HANDLE ROTATION
CHASSIS

MODEL 1102-3258

90º
1102

5"
127.5 MM

1-3/16"
30 MM
1-5/16"
33.5 MM

O.D. 3-3/16"
3-3/16" 9/16"
3-15/16" 80 MM Ø81 MM 14 MM
100.5 MM
O.D. 5/8"
Ø16 MM

FINISH: PRIMER
EXPLODED VIEW
WEIGHT: 8.28 LBS / 3.76 Kg

1110-4549
DETENT BALL
(2 pcs.) 1105-1257-2
PIN
1110-4550 .
.
DETENT SPRING Standard locking clearance
. Dual Grease Fittings
. Weld chamfer on Housing

1110-4503 Designed to hang straight for welding
GREASE FITTING
(2 pcs.) 1109-1257-1
HOUSING

1110-4511
LOCK NUT
1110-4510-G8
HEX BOLT PLEASE NOTE: Not all Twistlocks are supplied with an
integral handle latch. All Twistlocks should be outfitted
1107-8533-4
HANDLE with a handle latch upon installation. See section 1108
for latches that may work for your application.

904-696-0010
E-mail: sales@buffersusa.com
1102-12 11/29/23
