TWISTLOCKS – DROP-IN TYPE
90° HANDLE ROTATION
CHASSIS

MODEL 1102-1259-R
MODEL 1102-1259-L

3-3/16"
81 MM
90º
1102

3-9/16" 7-1/2"
90.5 MM 190.5 MM

MODEL 1102-1259-R MODEL 1102-1259-L
for Front Roadside for Front Curbside
1-3/16" & Rear Curbside & Rear Roadside
30 MM

1-5/16"
33.5 MM

3-1/8" O.D. 3-3/16" 9/16"
3-15/16" 80 MM Ø81 MM
100.5 MM 14 MM
O.D. 3/4"
Ø19 MM

FINISH: PRIMER
EXPLODED VIEW
WEIGHT: 9 LBS / 4.08 Kg

1110-4549
DETENT BALL 1105-1257-2 .
(2 pcs.) PIN Standard locking clearance
1110-4550 . Dual Grease Fittings
DETENT SPRING .
. Weld chamfer on Housing
Designed to hang straight for welding

1110-4503
GREASE FITTING
(2 pcs.) 1109-1257-1
HOUSING

1110-4511
LOCK NUT
1110-4524-G5
HEX BOLT
PLEASE NOTE: Not all Twistlocks are supplied with an
integral handle latch. All Twistlocks should be outfitted
1107-1259-4
HANDLE with a handle latch upon installation. See section 1108
for latches that may work for your application.
