1102-11
[return to Table of Contents]
TWISTLOCKS – DROP-IN TYPE
90° HANDLE ROTATION
CHASSIS

MODEL 1102-3229-R
MODEL 1102-3229-L

1-5/8"
41.3 MM

2" 7-1/4" 1102
50.8 MM 184.2 MM
90º

MODEL 1102-3229-R MODEL 1102-3229-L
for Front Roadside for Front Curbside
1-3/16" & Rear Curbside & Rear Roadside
30 MM

1-5/16"
33.5 MM

3-1/8" O.D. 3-3/16" 5/8"
3-15/16" 80 MM Ø81 MM 16 MM
100.5 MM

O.D. 3/4"
Ø19 MM

FINISH: PRIMER
EXPLODED VIEW WEIGHT: 9.15 LBS / 4.15 Kg

▪ Standard locking clearance
1110-4549 ▪ Dual Grease Fittings
DETENT BALL 1105-1257-2
(2 pcs.) PIN ▪ Handle designed for Narrow Bolsters
w/ limited space
1110-4550
DETENT SPRING

1110-4503
GREASE FITTING 1109-1257-1
(2 pcs.) HOUSING

1110-4511
LOCK NUT
1110-4524-G5
HEX BOLT PLEASE NOTE: Not all Twistlocks are supplied with an
1107-3229-4 integral handle latch. All Twistlocks should be outfitted with
HANDLE a handle latch upon installation. See section 1108 for latches
that may work for your application.

904-696-0010
E-mail: sales@buffersusa.com
1102-11 3/29/24
