TWISTLOCKS – DROP-IN TYPE
70° HANDLE ROTATION
CHASSIS

MODEL 1102-3248-R
MODEL 1102-3248-L
J.B. Hunt style

5-3/8"
136.6 MM
1102 70º
MODEL 1102-3248-R
for Front Roadside
3-13/16" 7-1/2" & Rear Curbside
96.5 MM 190.5 MM

MODEL 1102-3248-L
1-3/16"
30 MM for Front Curbside
& Rear Roadside
9/16"
1-1/16" 14 MM
27 MM
O.D. 3-3/16"
3-3/8"
4-1/16" 86.5 MM Ø81 MM
103.5 MM
O.D. 3/4"
Ø19 MM

EXPLODED VIEW FINISH: PRIMER
WEIGHT: 9.48 LBS / 4.3 Kg

1110-4501
DETENT BALL .
(2 pcs.)
1110-4502 J.B. Hunt style for Thin Flange
DETENT SPRING 1105-1257-2 Container Fittings
. Does not lock over standard ISO
PIN
. Dual Grease Fittings
Corner Fitting

1110-4503
GREASE FITTING
(2 pcs.) 1109-3248-1
HOUSING

1110-4511
LOCK NUT
1110-4524-G5
HEX BOLT PLEASE NOTE: Not all Twistlocks are supplied with an
integral handle latch. All Twistlocks should be outfitted
1107-3248-4
HANDLE with a handle latch upon installation. See section 1108
for latches that may work for your application.
