2903-02
[return to Table of Contents]
WEB WINCHES & WINCH RAILS

ISO FLATRACK, FLATBED & AUTO TRAILERS

MODEL 2903-2798 RAIL FOR SLIDING WINCHES
WEB WINCH, LEG BRACKET
for 4" webbing, Side Mount, MODEL 2903-2471
Weld-on LENGTH: 19-1/2" / 495.3 MM
WEIGHT: 11.4 LBS / 5.2 Kg

7-15/16" 1/4"
PAINTED BLACK 201.5 MM 6.4 MM
1-3/4"
4-15/16" 44.5 MM
125.6 MM
4-3/4"
4-13/16" 4-5/8" 119 MM
121.75 MM 118.4 MM
FITS: ISO FLATRACKS SUB FOR:
ANCRA 41691-12, KINEDYNE 12004 MATERIAL: FAB. STEEL FINISH: SELF-COLOR
WEIGHT: 8.1 LBS / 3.67 Kg
MODEL 2903-8665
WEB WINCH, SLIDER
w/ Double-L Track Cutout
for 4" webbing, Weld-on
PAINTED BLACK
3-15/16" 8"
100 MM 202.5 MM
5-15/16"
150 MM

3-7/16" 4-7/8" 5/16"
87 MM 124 MM 8 MM
FITS: MANAC
SUB FOR: KINEDYNE 1020
WEIGHT: 8.7 LBS / 3.95 Kg
2903

NOTE: FOR LOAD SECURING ONLY, NOT FOR LIFTING. WORKING LOAD LIMIT (WLL): 5,000 LBS / 2,267 Kg
ALL WINCH AND STRAP ASSEMBLIES SHOULD BE BREAK STRENGTH (BS): 15,000 LBS / 6,800 Kg
INSPECTED FOR FRAYS, CUTS, OR DAMAGED
HARDWARE BEFORE AND AFTER USING. DESIGNED TO MEET OR EXCEED WSTDA T-3 STANDARD.

904-696-0010
E-mail: sales@buffersusa.com
2903-2 3/6/23
