2902-03
[return to Table of Contents]
D-RINGS, CARGO CONTROL
FLOOR CHAIN TIE-DOWNS
ISO FLATRACK, FLATBED & AUTO TRAILERS

D-RING MODEL 3701-1177
9/16" STRAP MODEL 2902-1160-2
Ø14 MM

2-15/16" 15/16"
74 MM 24.5 MM
1/4"
6 MM
3-7/16" 1-1/4"
87 MM
32 MM SWL: 5,000 LBS / 2,268 Kg
4-11/16" MBS: 15,000 LBS / 6,804 Kg
119 MM
3701-1177 D-RING 2902-1160-2-SC or -HDG STRAP
MATERIAL: FORGED STEEL FINISH: SELF-COLOR MATERIAL: FORGED STEEL FINISH: SELF-COLOR or HDG
WEIGHT: 0.77 LBS / 0.35 Kg WEIGHT: 0.54 LBS / 0.24 Kg

1" 2" 45º MODEL 3701-7577-KIT
25.4 MM 51 MM
CHAIN TIE-DOWN ANCHOR

2-9/32"
58 MM 90º

6-27/32"
5-5/8" 173.6 MM
143 MM
FUNCTIONAL AT MIN. 45º
2-1/8" TO EITHER SIDE OF
54 MM VERTICAL CENTER. FUNCTIONAL AT MIN. 90º
FROM VERTICAL CENTER
TOWARD CARGO AREA.
2902
3-9/16" 1/2" SWL: 5,000 LBS / 2,268 Kg
90.5 MM 13.5 MM MBS: 15,000 LBS / 6,804 Kg WEIGHT: 2.04 LBS / 0.93 Kg

4" 3-3/4" MODEL 2902-2778
Ø2" 2-13/32" CHAIN TIE-DOWN ANCHOR
1-3/8"
1"
3-1/4"

1-1/2"
Ø7/16"
x 4 HOLES

3" FINISH: HDG
STAINLESS STEEL COVER PLATE, ALLOY STEEL WEIGHT: 5.87 LBS / 2.66 Kg
CLEVIS PINS (2 PCS), STAINLESS STEEL COTTER PINS (2 PCS),
3/8" (10 MM) ALLOY STEEL GR 70 CHAIN WORKING LOAD LIMIT (WLL): 5,400 LBS / 2,449 Kg
