2902-01
[return to Table of Contents]
D-RINGS w/ STRAPS

ISO FLATRACK, FLATBED & AUTO TRAILERS

A C
STANDARD-TYPE D-RINGS
NOTE: D-Ring strength for tie-down
B purposes only. NOT FOR LIFTING.
FINISH:
SC – SELF-COLOR E
HDG – HOT-DIP GALVANIZED G
PR – PRIMER D F D-RING DIMENSIONS STRAP DIMENSIONS
MODEL DESC. FINISH WEIGHT SWL MBS A B C D E F G
0.62 LBS
2902-6367-1-SC D-RING SC 0.28 Kg 3,333 LBS 10,000 LBS 2-7/16" 2-7/16" 3/8" 1-1/2" 3/4" 1-1/2" 1/4"
0.2 LBS 1,512 Kg 4,536 Kg 62.4 MM 62.6 MM 10 MM 38 MM 19 MM 38 MM 6 MM
2902-6367-2-SC STRAP SC
0.09 Kg
1.3 LBS
2902-7576-1-SC D-RING SC 0.59 Kg 6,333 LBS 19,000 LBS 4-1/4" 4-1/4" 5/8" 2-1/2" 1-3/16" 1-3/4" 3/8"
0.75 LBS 2,873 Kg 8,618 Kg 108.2 MM 108.2 MM 16 MM 63.5 MM 30 MM 44.5 MM 9 MM
2902-7576-2-SC STRAP SC
0.34 Kg
1.64 LBS
2902-6490-1-PR D-RING PR 0.74 Kg
1-3/8"
3/4"
3/8"
1-7/8"
SPECIAL ORDER ONLY 9,000 LBS 27,000 LBS 4-1/2" 4-1/2" 19 MM 2-11/16" 34 MM 47 MM 9 MM
68 MM
4,082 Kg
12,247 Kg 114.2 MM 114.2 MM
2902-6490-2-PR STRAP PR 0.94 LBS
0.43 Kg
1.97 LBS
2902-7399-1-HDG D-RING HDG 0.89 Kg
2902-7399-1-SC D-RING SC 1.97 LBS 14,000 LBS 42,000 LBS 5" 5" 3/4" 3-1/8" 1-3/8" 1-7/8" 3/8"
0.89 Kg 6,350 Kg 19,050 Kg 127 MM 127 MM 19 MM 80 MM 34 MM 47 MM 9 MM
0.89 LBS
2902-7399-2-SC STRAP SC 0.4 Kg
3.06 LBS
2902-7593-1-SC D-RING SC 1.39 Kg 15,667 LBS 47,000 LBS 5" 5" 1" 2-9/16" 1-11/16" 2-1/4" 7/16"
1.2 LBS 7,106 Kg 21,319 Kg 127 MM 127 MM 25.4 MM 65 MM 43 MM 56 MM 11 MM
2902-1578-2-SC STRAP SC
0.54 Kg
3.25 LBS
2902-1578-1-HDG D-RING HDG 1.47 Kg
2902-1578-1-SC D-RING SC 3.7 LBS
1.68 Kg 15,667 LBS 47,000 LBS 5" 6" 1" 2-9/16" 1-11/16" 2-1/4" 7/16"
1.2 LBS 7,106 Kg 21,319 Kg 127 MM 152.4 MM 25.4 MM 65 MM 43 MM 56 MM 11 MM
2902 2902-1578-2-HDG STRAP HDG 0.54 Kg
2902-1578-2-SC STRAP SC 1.2 LBS
0.54 Kg
A C
STANDARD-TYPE D-RINGS
NOTE: D-Ring strength for tie-down
*
B purposes only. NOT FOR LIFTING.
FINISH: *D-Ring shown w/ 2902-7669 Bolt-On Strap
SC – SELF-COLOR G E
ZP – ZINC-PLATED D F D-RING DIMENSIONS STRAP DIMENSIONS
MODEL DESC. FINISH WEIGHT SWL MBS A B C D E F G
0.64 LBS
2902-7668-1-ZP D-RING ZP
0.29 Kg
0.25 LBS 3,333 LBS 10,000 LBS 1-5/8" 1/4"
2902-7668-2-SC STRAP SC 0.11 Kg 1,512 Kg 4,536 Kg 41.2 MM 5.7 MM
0.4 LBS
2902-7669 STRAP ZP
0.18 Kg 3-1/4" 3-1/2" 1/2" 7/8" 1-1/16"
2902-8477-1-SC 0.55 LBS 82.5 MM 88.9 MM 12.7 MM 22.7 MM 27 MM
Military applications D-RING SC 0.25 Kg
2902-8477-1-ZP D-RING ZP 0.55 LBS 4,100 LBS 12,300 LBS 3/4" 5/16"
Military applications 0.25 Kg 1,859 Kg 5,579 Kg 45 MM 7 MM
2902-8477-2-SC 0.35 LBS
Military applications STRAP SC 0.16 Kg
