1401-12
[return to Table of Contents]
SWING DOOR LOCKING SYSTEMS
MINER-STYLE COMPONENTS
TOP & BOTTOM CAMS
DRY VAN TRAILERS

MODEL 1401-2581-L/R
TOP & BOTTOM CAM

2-1/16"
52.8 MM
1-3/8" 4-9/16"
34.4 MM 116 MM
2-1/2"
2-7/16" 63.2 MM
62.2 MM
O.D. 1-1/16"
Ø27 MM MODEL 1401-2581-L MODEL 1401-2581-R
Top Right or Bottom Left Top Left or Bottom Right
SUB FOR: MINER 4044 (L) & 4043 (R) TYPE: DL WORKS WITH: 1401-2580 & 1401-2593 KEEPERS
MATERIAL: FORGED STEEL FINISH: GALVANIZED WEIGHT: 1.35 LBS / 0.64 Kg

MODEL 1401-2592-L/R
2-1/16" TOP & BOTTOM CAM
1-3/8" 52.8 MM
34.4 MM
1401
2-7/16"
62.2 MM 6-7/8"
174 MM
O.D. 1-1/16" 4-13/16"
Ø27 MM 121.2 MM

O.D. 5/8"
Ø15 MM MODEL 1401-2592-L MODEL 1401-2592-R
Top Right or Bottom Left Top Left or Bottom Right
SUB FOR: MINER 2092 (L) & 2091 (R) TYPE: CT WORKS WITH: 1401-2580 & 1401-2593 KEEPERS
MATERIAL: FORGED STEEL FINISH: GALVANIZED WEIGHT: 1.8 LBS / 0.82 Kg

O.D. 5/8" MODEL 1401-2598
Ø15 MM
BOTTOM CAM
3-1/16" 3-1/8" Right-locking only
77.5 MM O.D. 1-1/16" 78.8 MM
Ø27 MM
1-5/16"
33.3 MM 6-13/16"
175 MM
I.D. 5/8"
Ø16 MM 3-3/16"
80.5 MM
1-1/4" 1-13/16"
31.5 MM 46 MM

I.D. Ø5/8"
SUB FOR: MINER 4144 TYPE: SC WORKS WITH: 1401-2600 KEEPER Hole for
MATERIAL: FORGED STEEL FINISH: GALVANIZED WEIGHT: 1.81 LBS / 0.82 Kg Security Seal

904-696-0010
E-mail: sales@buffersusa.com
1401-12 2/20/23
