1401-08
[return to Table of Contents]
SWING DOOR LOCKING SYSTEMS
EBERHARD- & MINER-STYLE COMPONENTS
TOP & BOTTOM KEEPERS
DRY VAN TRAILERS

MODEL 1401-2580 MODEL 1401-2593
TOP & BOTTOM KEEPER TOP & BOTTOM KEEPER
3/4" Non-Handed 1/8" Non-Handed w/ 1/8" offset
18 MM Offset
2" 2-1/8"
51 MM 1-1/8" 54 MM 1-3/16"
28 MM 30 MM

1-3/8" 2-1/16" 1-11/16" 2"
34 MM 52 MM NO 42.1 MM 51 MM
1/8"
OFFSET OFFSET
2-7/8" 2-15/16"
72 MM 73.6 MM
SUB FOR: MINER M1064 TYPE: CT or DL SUB FOR: MINER M4091 TYPE: CT or DL
WORKS WITH: BUFFERS 1401-2581 & 1401-2592 CAMS WORKS WITH: BUFFERS 1401-2581 & 1401-2592 CAMS
MATERIAL: CAST STEEL FINISH: HOT-DIP GALVANIZED MATERIAL: CAST STEEL FINISH: HOT-DIP GALVANIZED
WEIGHT: 1.06 LBS / 0.48 Kg WEIGHT: 1.2 LBS / 0.54 Kg

MODEL 1401-2599 I.D. 1/2" MODEL 1401-2600
2-1/8" TOP & BOTTOM KEEPER Ø12.7 MM BOTTOM KEEPER
54 MM
Non-Handed 1-11/16" Non-Handed
42.1 MM
1-9/16"
1-3/8"
1401 34.9 MM 39.7 MM
2" 1-3/16" Security Hole
50.8 MM 29.4 MM
3-13/16"
95.9 MM
2"
1-5/8" 50.8 MM
40.5 MM
3-5/8" 3-5/16"
92.1 MM 84.1 MM
SUB FOR: MINER M4224 TYPE: NS SUB FOR: MINER M4143 TYPE: SC
WORKS WITH: BUFFERS 1401-2741-L/R CAMS WORKS WITH: BUFFERS 1401-2598 CAM
MATERIAL: FORGED STEEL FINISH: ZINC-PLATED MATERIAL: CAST STEEL FINISH: HOT-DIP GALVANIZED
WEIGHT: 0.84 LB / 0.38 Kg WEIGHT: 1.28 LBS / 0.58 Kg

3/8"
MODEL 1401-2719 9.5 MM MODEL 1401-6517-L/R
BOTTOM KEEPER TOP KEEPER
Non-Handed Narrow Header
2"
50.8 MM
13/16" 13/16"
20.5 MM 20.5 MM
3-3/4"
95.3 MM 1-1/4" 1-7/16"
15/16" 31.7 MM 36 MM 1401-6517-L
24.4 MM
1-9/16"
39.7 MM
1-3/8" 5/16" 4-7/8" 1-1/8"
34.9 MM 7.94 MM 123.3 MM 29 MM 1401-6517-R

SUB FOR: MINER M4223 TYPE: HV SUB FOR: EBERHARD 16436-L/R, GREAT DANE 42500114 (L)
WORKS WITH: BUFFERS 1401-7132-BL/BR CAMS & 42500113 (R) WORKS WITH: BUFFERS 1401-6518-L/-R CAMS
MATERIAL: CAST STEEL FINISH: HOT-DIP GALVANIZED MATERIAL: FORGED STEEL FINISH: HOT-DIP GALVANIZED
WEIGHT: 0.95 LB / 0.43 Kg WEIGHT: 0.5 LB / 0.23 Kg
